纽荷兰零件查询(F5CE5454B A005) - ENGINE 504387947 - 84230116 (10.106.AA) - CAMSHAFT New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
135 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 504272265 | [1] | CAMSHAFT | TORIncl 2 |
| 1. | 504272265R | [1] | REMAN-CAMSHAFT | RACC232 COMPACT TRACK LOADER, L225 SKID STEER LOADER, Both (4/11-), F5CE5454B A005 ENGINE 504387947 - 84230116, L225 SKID STEER LOADER - NRC L25VWN (1/13-) |
| 1. | 504272265C | [1] | | RACReturn Number |
| 2. | 10839510 | [1] | DOWEL,M6 x 9 | TTF Superseded by part number: 17275310 |
| 3. | 4897457 | [1] | SUPPORT | TOR |
| 4. | 98471524 | [8] | TAPPET | TOR |
| 5. | 504163240 | [8] | PUSH ROD | TOR |
| 6. | 2852234 | [2] | FLANGE BOLT,Hex, M8 x 1.25 x 20mm | TOR Superseded by part number: 16978124 |
| 7. | 504240396 | [1] | GEAR | TOR |
| 8. | 16673635 | [6] | BOLT,Hex, M8 x 1.25 x 20mm, Full Thd | TOR Superseded by part number: 16978124 |
