凯斯零件查询(8465T) - CASE IH ROUND BALER W/TRACTOR HYDRAULICS (1/91-12/97) (7-02) - HITCH AND JACK ASSEMBLY Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
918 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
63768
|
[1] |
PIN
|
CAS
AND CHAIN - linch
|
| 2. |
700114468
|
[2] |
WASHER,26.19mm ID x 63.5mm OD x 6mm Thk
|
IH
- special
|
| 3. |
495-11106
|
[4] |
WASHER,1", SAE
|
CAS
Superseded by part number: 87367
|
| 4. |
425-1216
|
[1] |
SLOTTED NUT,Hex, 1"-8, G5
|
CAS
Superseded by part number: 87343900
|
| 5. |
413-1056
|
[1] |
BOLT,Hex, 5/8" - 11 x 3-1/2", Gr 5
|
CAS
Superseded by part number: 280119
|
| 6. |
230-41110
|
[1] |
LOCK NUT,5/8"-11, GA
|
CAS
5/8-11 HTLN GR/B Superseded by part number: 85700693
|
| 7. |
148558C1
|
[1] |
CLEVIS
|
IH
- safety, chain Superseded by part number: 1279163C1
|
| 8. |
6649982
|
[1] |
HUB
|
IH
- idler
|
| 9. |
432-1240
|
[1] |
COTTER PIN,3/16" x 2 1/2"
|
CAS
3/16" x 2 1/2" Superseded by part number: 86523959
|
| 10. |
700125679
|
[1] |
HITCH PIN
|
IH
PIN - hitch
|
| 11. |
252411
|
[1] |
SPACER
|
HFI
|
| 12. |
700705598
|
[1] |
CHAIN (CE)
|
CAS
SAFETY - chain
|
| 13. |
D51609
|
[1] |
BALL JOINT
|
CAS
BEARING - tongue
|
| 14. |
6227391
|
[1] |
TUBE,2" OD, 1.88" Length
|
CAS
- wa
|
| 15. |
700706826
|
[1] |
JACK
|
IH
|
| 16. |
700706640
|
[1] |
PIN
|
L
AND CHAIN ASSEMBLY
|
| 17. |
700711826
|
[1] |
JACK
|
CAS
KIT - service, t.w.
|
