凯斯零件查询(8465T) - CASE IH ROUND BALER W/TRACTOR HYDRAULICS (1/91-12/97) (7-04) - MAINFRAME, TONGUE AND AXLE ASSEMBLIES Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
854 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700114235
|
[1] |
SUPPORT
|
HFI
- idler
|
| 2. |
432-1024
|
[2] |
COTTER PIN,5/32" x 1 1/2"
|
CAS
5/32" x 1 1/2" Superseded by part number: 72187233, 88350
|
| 3. |
425-1210
|
[2] |
SLOTTED NUT,Hex, 5/8"-11, G5
|
CAS
|
| 4. |
451542
|
[2] |
SPACER
|
HFI
|
| 5. |
700114344
|
[2] |
SCREW
|
CAS
- special
|
| 6. |
700114285
|
[1] |
AXLE
|
HFI
- wa
|
| 7. |
700125024
|
[1] |
TOW BAR
|
HFI
TONGUE WA
|
| 8. |
219-93
|
[2] |
LUBE NIPPLE,90 Degree Elbow, 1/4" - 28 NPTF
|
CAS
Superseded by part number: 87415
|
| 9. |
700119003
|
[1] |
SIDE ASSY.
|
HFI
SIDE WA - right
|
| 10. |
409-7612
|
[8] |
BOLT,3/8"-16 x 1.09" OAL
|
CAS
3/8-16 X 3/4 HWHMS Superseded by part number: 72187187, 255918
|
| 11. |
232-5316
|
[15] |
FLANGE NUT,Flg, 3/8"-16
|
CAS
3/8-16 HFTLN GR/G Superseded by part number: 86521609
|
| 12. |
700117098
|
[2] |
CHANNEL
|
HFI
|
| 13. |
700114349
|
[1] |
SUPPORT
|
HFI
- front
|
| 14. |
700114239
|
[1] |
ARM
|
HFI
SUPPORT - right, weldment
|
| 15. |
700126380
|
[1] |
SIDE ASSY.
|
HFI
SIDE WA - left
|
| 16. |
700118826
|
[2] |
SHIM
|
HFI
|
| 17. |
413-620
|
[7] |
BOLT,Hex, 3/8" - 16 x 1-1/4", Gr 5
|
CAS
C Hex, 3/8"-16 x 1 1/4", G5, Full Thd Superseded by part number: 72187207, 88011
|
| 18. |
413-588
|
[2] |
BOLT,Hex, 5/16" - 18 x 5-1/2", Gr 5
|
CAS
5/16-18 X 5-1/2 C Superseded by part number: 88812
|
| 19. |
232-5315
|
[2] |
FLANGE NUT,Flg, 5/16"-18
|
CAS
5/16-18 HFTLN GR/G
|
| 20. |
700118603
|
[2] |
SUPPORT
|
HFI
|
| 21. |
700114238
|
[1] |
ARM
|
CAS
SUPPORT - left, weldment
|
