纽荷兰零件查询(F5CE5454B A005) - ENGINE 504387947 - 84230116 (10.414.AD) - BELT PULLEY DRIVE & COVER New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
999 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 504255374 | [1] | FAN HOUSING | TORIncl 2 - 6, 8 |
| 2. | 4892732 | [1] | BALL BEARING,34mm ID x 64mm OD x 37mm W | TOR |
| 3. | 4890732 | [1] | RETAINER,11.50mm ID x 52mm OD x 7mm | TOR |
| 4. | 32324 | [1] | SNAP RING,2.44", Int, #244 | GI |
| 5. | 2852172 | [1] | BOLT,Flng, M10 x 1.5 x 70mm | TOR Superseded by part number: 16676834 |
| 6. | 504255371 | [1] | HUB | TOR |
| 7. | 16673735 | [5] | BOLT,Hex, M8 x 1.25 x 25mm | TOR Superseded by part number: 10278301 |
| 8. | NSS | [1] | NOT SERVICED SEPARATELY | CONHousing, Incl in 1 |
| 9. | 18139424 | [4] | SCREW,Hex, M10 x 20mm | TOR |
| 10. | 504388091 | [1] | | PULLEY |
