凯斯零件查询(8465T) - CASE IH ROUND BALER W/TRACTOR HYDRAULICS (1/91-12/97) (6-30) - FORMING BELTS AND LACING, CLIPPER BELT, SERIAL NUMBER CFH0074001 THROUGH CFH0074591, Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
457 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700709999
|
[8] |
BELT,177.00 mm W x 14287.5 mm L
|
CAS
177.00 mm W x 14287.5 mm
|
| 2. |
700710206
|
[8] |
PIN,1.73mm OD x 180mm L
|
L
- lacing
|
| 3. |
700707322
|
[16] |
LATCH ASSY.
|
L
FASTENER
|
| 4. |
700713342
|
[8] |
PIN
|
L
- lacing Superseded by part number: 700719731
|
| 5. |
700713617
|
[8] |
BELT,177.00 mm W x 14287.50 mm L
|
L
|
