凯斯零件查询(8465T) - CASE IH ROUND BALER W/TRACTOR HYDRAULICS (1/91-12/97) (5-02) - TAILGATE LATCH ASSEMBLY Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
391 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700115942
|
[2] |
PLATE
|
HFI
|
| 2. |
700119111
|
[1] |
LATCH
|
CAS
WA - left
|
| 3. |
700119092
|
[1] |
SUPPORT
|
HFI
- left
|
| 4. |
700119106
|
[1] |
LATCH
|
CAS
WA - left
|
| 5. |
432-1020
|
[6] |
COTTER PIN,5/32" x 1 1/4"
|
CAS
PIN, SPLIT (COTTER), 5/32" x 1 1/4" Superseded by part number: 86523851
|
| 6. |
700115939
|
[2] |
PIN
|
HFI
|
| 7. |
700115941
|
[4] |
LINK
|
CAS
|
| 8. |
195-2117
|
[2] |
WASHER,13/16" x 1 1/2" x .134", HDN
|
CAS
3/4 X 10 GAUGE WRMB
|
| 9. |
700115920
|
[2] |
LINK
|
CAS
WA
|
| 10. |
700109079
|
[2] |
SPACER
|
HFI
|
| 11. |
700119108
|
[1] |
LATCH
|
CAS
WA - right
|
| 12. |
488122
|
[2] |
SPACER
|
HFI
TUBE - spacer
|
| 13. |
763870
|
[2] |
CLEVIS PIN
|
CAS
5/8 X 4 CLEVIS PIN
|
| 14. |
51200241
|
[2] |
SPACER
|
CAS
|
| 15. |
700115929
|
[2] |
PIN
|
CAS
WA
|
| 16. |
700115918
|
[2] |
PIN
|
CAS
WA
|
| 17. |
413-616
|
[4] |
BOLT,Hex, 3/8" - 16 x 1", Gr 5
|
CAS
Superseded by part number: 88206, 72187206
|
| 18. |
231-5146
|
[4] |
FLANGE NUT,3/8"-16
|
CAS
Superseded by part number: 72187068, 247780
|
| 19. |
6287155
|
[4] |
SPACER
|
HFI
|
| 20. |
758441
|
[2] |
SPRING
|
IH
- extension
|
| 21. |
700119112
|
[1] |
LATCH
|
CAS
WA - right
|
| 22. |
700119093
|
[1] |
SUPPORT
|
HFI
- right
|
| 23. |
433-824
|
[4] |
CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 1 1/2", Gr 5
|
CAS
1/2-13 X 1-1/2 RHSNB Superseded by part number: 280420, 72187237
|
| 24. |
80679
|
[4] |
LOCK WASHER,1/20.507 CST ZND
|
NH
WASHER, LOCK, 1/2"
|
| 25. |
425-108
|
[10] |
NUT,1/2" - 13, Gr 5
|
CAS
NUT, 1/2"-13, G5 Superseded by part number: 280431
|
| 26. |
873422
|
[2] |
CAPSCREW,Hex, 1/2" - 13 x 3 1/2", Gr 5, Full Thd
|
CAS
1/2-13 X 3-1/2 FTC
|
