纽荷兰零件查询(F5CE5454C A003) - ENGINE 504387948 - 84171653 (10.102.03) - FLYWHEEL CASE (504380467) New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
611 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 504380468 | [1] | HOUSING | TOR |
| 2. | 16673935 | [2] | BOLT,Hex, M8 x 35mm | TORM8 x 35 mm |
| 3. | 504268669 | [1] | PLATE | TOR |
| 4. | 16678435 | [6] | BOLT | TORM12 x 60 mm |
| 5. | 504351177 | [2] | M8 x 1,25 | SCREW,M8 x 1.25 |
| 6. | 2995644 | [1] | SEALANT | TOR |
| 7. | 4895378 | [1] | BUTTON PLUG,M29.2 | TOR |
| 8. | 4895379 | [1] | O-RING,21.82mm ID x 3.53mm Width | TOR Superseded by part number: 17288480 |
