纽荷兰零件查询(F5CE5454C A003) - ENGINE 504387948 - 84171653 (10.102.02) - ENGINE BLOCK FRONT COVER (5801361473) New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
875 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 504244214 | [1] | COVER | TOR- ASSY |
| 2. | 504051236 | [1] | PLUG,Threaded, 1/8" | TORD.=1/8" |
| 3. | 504204989 | [1] | LUBE OIL NOZZLE | TORLUBE OIL JET NOZZLE |
| 4. | 504389774 | [1] | | COVER |
| 5. | 504244287 | [1] | GASKET | TOR |
| 6. | 16586424 | [3] | SCREW,M8 x 25mm | TORM8 x 25 Superseded by part number: 16673735 |
| 6. | 16586624 | [2] | SCREW,M8 x 35mm | TORM8 x 35 Superseded by part number: 16586625 |
| 7. | 16586625 | [11] | BOLT,M8 x 35mm | TORM8 x 35 |
| 8. | 4798845 | [2] | BOLT,M8 x 1.25 x 16.50mm | TOR |
| 9. | 10300611 | [1] | PLUG,M14 x 1.5 x 14, Cl5.8 | BAS Superseded by part number: 16992315 |
| 10. | 4858608 | [1] | SEAL,14mm ID x 19.50mm OD x 1.50mm Thk | TTFD. 14X20X1,5 mm Superseded by part number: 2852356 |
| 11. | 99435557 | [4] | DOWEL,8.50mm Dia | TORD. 8,5 mm Superseded by part number: 2852481 |
| 12. | 16586924 | [6] | BOLT,Hex, M8 x 50mm | TORM8 x 50 Superseded by part number: 16586925 |
| 13. | 98401723 | [5] | BOLT,Hex, M8 x 1.25 x 12mm | TOR |
| 14. | 2995644 | [1] | SEALANT | TOR- NOT ILLUSTRATED |
