纽荷兰零件查询(F5CE5454C A003) - ENGINE 504387948 - 84171653 (10.218.02[02]) - INJECTION EQUIPMENT - INJECTOR (504385855) New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
223 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 504385978 | [4] | FUEL SYSTEM INJECTOR | TOR |
| 1. | 504385978R | [4] | REMAN-INJECT NOZZLE | TOR |
| 1. | 504385978C | [4] | CORE-NOZZLE, INJECT | TORReturn Number |
| 2. | 504385832 | [4] | BRACKET | TOR |
| 3. | 504315404 | [4] | STUD,M8 x 16 x 60mm | TORM8X16X60 |
| 4. | 500353601 | [4] | WASHER | TOR |
| 5. | 17044735 | [4] | NUT,Hex, M8 | TORM8 |
| 7. | 4899689 | [4] | SEALING WASHER,7mm ID x 15mm OD x 1.5mm Thk | TORD = 14 MM SP = 1,78 MM |
