| 1. |
700120270
|
[1] |
WASHER
|
CAS
- special
|
| 2. |
700711557
|
[1] |
WASHER
|
CAS
1/2 HARDENED WIDE PLAIN WASHER
|
| 3. |
52233
|
[3] |
BUSHING
|
CAS
5/8 X 14 GAUGE NRMB Superseded by part number: 51200381
|
| 4. |
8701237
|
[1] |
BOLT
|
CAS
1/2-13 X 1-1/2 HFS GR8
|
| 5. |
413-516
|
[8] |
BOLT,Hex, 5/16" - 18 x 1", Gr 5
|
CAS
C Hex, 5/16"-18 x 1", G5, Full Thd Superseded by part number: 9635884, 72187198
|
| 6. |
492-11031
|
[22] |
LOCK WASHER,5/16"
|
CAS
WASHER, LOCK, 5/16" Superseded by part number: 83990583
|
| 7. |
495-61034
|
[1] |
WASHER,0.34" ID x 0.88" OD x 0.06" Thk
|
CAS
5/16 WIDE PLAIN WASHER
|
| 8. |
541857R92
|
[1] |
SPROCKET,15T
|
IH
IDLER - sprocket 15 tooth
|
| 9. |
700709424
|
[1] |
TIGHTENER
|
CAS
SLIDE - chain
|
| 10. |
611362R91
|
[1] |
CHAIN (AG)
|
IH
CHAIN - roller #60 (10 foot bulk) Superseded by part number: 611362R91X
|
| 11. |
241-1416
|
[1] |
LINK
|
CAS
- connector, #60 R/C Superseded by part number: 241-1316
|
| 12. |
425-108
|
[6] |
NUT,1/2" - 13, Gr 5
|
CAS
NUT, 1/2"-13, G5 Superseded by part number: 280431
|
| 13. |
700715225
|
[1] |
EYEBOLT,1/2" - 13 x 6"
|
CAS
1/2-13 EYE-BOLT
|
| 14. |
495-21056
|
[4] |
WASHER,1/2"
|
CAS
1/2 HARDENED PLAIN WASHER Superseded by part number: 72187265, 80700
|
| 15. |
433-628
|
[3] |
CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 1 3/4", Gr 5
|
CAS
3/8-16 X 1-3/4 RHSNB Superseded by part number: 86508775
|
| 16. |
496-11041
|
[3] |
WASHER,13/32" x 13/16" x .065", HDN
|
CAS
3/8 HARDENED PLAIN WASHER Superseded by part number: 86632588
|
| 17. |
492-11038
|
[7] |
LOCK WASHER,3/8"
|
CAS
Superseded by part number: 80680, 72187249
|
| 18. |
425-106
|
[7] |
NUT,3/8"-16, Cl 5
|
CAS
Superseded by part number: 9628503
|
| 19. |
700122939
|
[1] |
SUPPORT
|
HFI
- left
|
| 20. |
86636814
|
[1] |
LUBE NIPPLE,1/4"-28 x .52" lg
|
GI
1/4-28 X 45 DEGREE ZERK Superseded by part number: 88775
|
| 21. |
700126728
|
[1] |
SHIM
|
HFI
|
| 22. |
700119327
|
[1] |
SPACER
|
CAS
- pivot
|
| 23. |
433-832
|
[1] |
CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 2", Gr 5
|
CAS
1/2-13 X 2 RHSNB Superseded by part number: 280185
|
| 24. |
80679
|
[4] |
LOCK WASHER,1/20.507 CST ZND
|
NH
WASHER, LOCK, 1/2"
|
| 25. |
700119326
|
[1] |
FLANGE
|
CAS
|
| 26. |
T27207
|
[2] |
FLANGED BEARING
|
CAS
FLANGE - bearing Superseded by part number: 617863R1
|
| 27. |
517645R11
|
[1] |
COLLAR
|
IH
BEARING - spherical (Includes collar) Superseded by part number: 47577188
|
| 28. |
433-820
|
[2] |
CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 1 1/4", Gr 5
|
CAS
1/2-13 X 1-1/4 RHSNB Superseded by part number: 87868
|
| 29. |
700120267
|
[1] |
COLLAR
|
CAS
ASSEMBLY (Includes Item 30)
|
| 30. |
700709621
|
[2] |
SPHERICAL BEARING,31.78mm Hex x 72mm OD x 25mm W
|
CAS
BEARING - spherical (hex bore) Superseded by part number: 47442495
|
| 31. |
700120269
|
[1] |
COLLAR
|
CAS
ASSEMBLY (Includes Item 30)
|
| 32. |
433-512
|
[8] |
CARRIAGE BOLT,Sq Nk, 5/16" - 18 x 3/4", Gr 5
|
CAS
Superseded by part number: 280327
|
| 33. |
425-105
|
[14] |
NUT,5/16"-18, G5
|
CAS
Superseded by part number: 9635082, 72187221
|
| 34. |
700709838
|
[1] |
ROLLER
|
HFI
WA
|
| 35. |
700120184
|
[1] |
SCRAPER
|
HFI
WA
|
| 36. |
700120200
|
[1] |
GUIDE
|
HFI
WA - belt
|
| 37. |
700122924
|
[1] |
SUPPORT
|
HFI
WA - scraper
|
| 38. |
111-237
|
[6] |
CARRIAGE BOLT,Short NK, 5/16"-18 x 1", G5
|
CAS
BOLT, CARRIAGE, Short NK, 5/16"-18 x 1", G5 Superseded by part number: 33-516
|
| 39. |
496-21034
|
[10] |
WASHER,11/32" x 11/16" x 0.89", HDN
|
CAS
Superseded by part number: 86637953
|
| 40. |
700120187
|
[1] |
SCRAPER
|
HFI
|
| 41. |
1322251C91
|
[1] |
COLLAR
|
IH
BEARING - spherical Superseded by part number: 563733
|
| 42. |
411-864
|
[1] |
CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 4", Gr 2
|
CAS
1/2-13 X 4 RHSNB Superseded by part number: 87495288
|
| 43. |
434-616
|
[5] |
CARRIAGE BOLT,Sht Sq Nk, 3/8" - 16 x 1", Gr 5
|
CAS
3/8-16 X 1 RHSSNB Superseded by part number: 80280503
|
| 44. |
231-4116
|
[5] |
NUT,3/8"-16, GB
|
CAS
3/8-16 HTLN GR/B Superseded by part number: 88902, E64197
|
| 45. |
700120247
|
[1] |
SUPPORT
|
HFI
HOUSING ASSEMBLY (Includes Item 41)
|
| 46. |
413-632
|
[4] |
BOLT,Hex, 3/8" - 16 x 2", Gr 5
|
CAS
Superseded by part number: 88436
|
| 47. |
700120256
|
[1] |
SPROCKET ASSY.
|
HFI
SPROCKET - 40 tooth
|
| 48. |
700120251
|
[1] |
HUB
|
HFI
- splined
|
