凯斯零件查询(8480) - CASE IH FIXED CHAMBER ROUND BALER (1/90-12/00) (2-12) - DRIVE ASSEMBLY, LOWER, LEFT, SERIAL NUMBER CFH0051673 AND LATER Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
181 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
858167
|
[1] |
SPRING
|
L
- extension
|
| 2. |
700126742
|
[1] |
ARM
|
HFI
WA
|
| 3. |
6179220
|
[1] |
SPACER
|
HFI
|
| 4. |
700126751
|
[1] |
SUPPORT
|
HFI
WA - left
|
| 5. |
219-93
|
[1] |
LUBE NIPPLE,90 Degree Elbow, 1/4" - 28 NPTF
|
CAS
Superseded by part number: 87415
|
| 6. |
413-1056
|
[1] |
BOLT,Hex, 5/8" - 11 x 3-1/2", Gr 5
|
CAS
Superseded by part number: 280119
|
| 7. |
396-21066
|
[1] |
WASHER,16.66mm ID x 33.33mm OD x 4.27mm Thk
|
CAS
- 5/8" bolt size 21/32" x 1 5/16" x .150", HDN Superseded by part number: 87613283
|
| 8. |
492-11062
|
[2] |
BEARING WASHER,5/8"
|
CAS
WASHER, LOCK, 5/8" Superseded by part number: 86729275
|
| 9. |
425-1010
|
[2] |
NUT,5/8"-11, G5
|
CAS
Superseded by part number: 280374
|
| 10. |
496-11041
|
[1] |
WASHER,13/32" x 13/16" x .065", HDN
|
CAS
3/8 HARDENED PLAIN WASHER Superseded by part number: 86632588
|
| 11. |
425-106
|
[2] |
NUT,3/8"-16, Cl 5
|
CAS
Superseded by part number: 9628503
|
| 12. |
413-1052
|
[1] |
BOLT,Hex, 5/8" - 11 x 3-1/4", Gr 5
|
CAS
5/8-11 X 3-1/4 C Superseded by part number: 9827853
|
| 13. |
6136964
|
[1] |
SPACER
|
HFI
- lower
|
| 14. |
662958R91
|
[1] |
PULLEY
|
IH
IDLER
|
| 15. |
219-8
|
[1] |
LUBE NIPPLE,1/4" - 28 NPTF
|
CAS
NIPPLE, LUBE, 1/4"-28 NPT x .54" lg Superseded by part number: 87414
|
| 16. |
51200285
|
[1] |
SCREW
|
CAS
DRAW - bolt
|
