凯斯零件查询(8480) - CASE IH FIXED CHAMBER ROUND BALER (1/90-12/00) (2-16) - IDLER ASSEMBLY, DRIVE CHAIN, LEFT Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
158 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700709641
|
[1] |
SPRING
|
CAS
|
| 2. |
413-1036
|
[1] |
BOLT,Hex, 5/8" - 11 x 2-1/4", Gr 5
|
CAS
5/8-11 X 2-1/4 C Superseded by part number: 88556
|
| 3. |
230-41110
|
[1] |
LOCK NUT,5/8"-11, GA
|
CAS
5/8-11 HTLN GR/B Superseded by part number: 85700693
|
| 4. |
52233
|
[4] |
BUSHING
|
CAS
5/8 X 14 GAUGE NRMB Superseded by part number: 51200381
|
| 5. |
541857R92
|
[1] |
SPROCKET,15T
|
IH
IDLER - sprocket, 15 tooth
|
| 6. |
52928
|
[3] |
WASHER
|
CAS
3/4 X 14 GAUGE WRMB
|
| 7. |
700120286
|
[1] |
ARM
|
HFI
- idler (Includes Item 9)
|
| 8. |
432-1220
|
[1] |
COTTER PIN,3/16" x 1 1/4"
|
CAS
3/16" x 1 1/4" Superseded by part number: 87398
|
| 9. |
711580
|
[1] |
BUSHING
|
CAS
|
