凯斯零件查询(8480) - CASE IH FIXED CHAMBER ROUND BALER (1/90-12/00) (2-18) - ROLLER AND DRIVE ASSEMBLY, FRONT Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
938 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
8701237
|
[1] |
BOLT
|
CAS
1/2-13 X 1-1/2 HFS GR8
|
| 2. |
700711557
|
[1] |
WASHER
|
CAS
1/2 HARDENED WIDE PLAIN WASHER
|
| 3. |
700120259
|
[1] |
SHEAVE
|
HFI
|
| 4. |
700120251
|
[1] |
HUB
|
HFI
- splined
|
| 5. |
413-640
|
[4] |
BOLT,Hex, 3/8" - 16 x 2-1/2", Gr 5
|
CAS
Superseded by part number: 87936
|
| 6. |
492-11038
|
[9] |
LOCK WASHER,3/8"
|
CAS
Superseded by part number: 80680, 72187249
|
| 7. |
425-106
|
[9] |
NUT,3/8"-16, Cl 5
|
CAS
Superseded by part number: 9628503
|
| 8. |
700120270
|
[1] |
WASHER
|
CAS
- special
|
| 9. |
700120255
|
[1] |
SPROCKET ASSY.
|
HFI
SPROCKET - 24 tooth
|
| 10. |
700120234
|
[1] |
HOUSING ASSY.
|
CAS
HOUSING ASSEMBLY (Includes Item 13)
|
| 11. |
434-616
|
[5] |
CARRIAGE BOLT,Sht Sq Nk, 3/8" - 16 x 1", Gr 5
|
CAS
3/8-16 X 1 RHSSNB Superseded by part number: 80280503
|
| 12. |
700709835
|
[1] |
ROLLER
|
HFI
- lower
|
| 13. |
1322251C91
|
[1] |
COLLAR
|
IH
BEARING - spherical Superseded by part number: 563733
|
| 14. |
413-516
|
[4] |
BOLT,Hex, 5/16" - 18 x 1", Gr 5
|
CAS
C Hex, 5/16"-18 x 1", G5, Full Thd Superseded by part number: 9635884, 72187198
|
| 15. |
492-11031
|
[4] |
LOCK WASHER,5/16"
|
CAS
WASHER, LOCK, 5/16" Superseded by part number: 83990583
|
| 16. |
700709621
|
[1] |
SPHERICAL BEARING,31.78mm Hex x 72mm OD x 25mm W
|
CAS
BEARING - spherical (hex bore) Superseded by part number: 47442495
|
| 17. |
700709836
|
[1] |
ROLLER
|
HFI
- upper
|
| 18. |
700120267
|
[1] |
COLLAR
|
CAS
ASSEMBLY (Includes Item 16)
|
