凯斯零件查询(8480) - CASE IH FIXED CHAMBER ROUND BALER (1/90-12/00) (2-22) - ROLLER AND TAILGATE PIVOT ASSEMBLIES Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
123 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
413-524
|
[12] |
BOLT,Hex, 5/16" - 18 x 1-1/2", Gr 5
|
IH
Superseded by part number: 88275, 72187199
|
| 2. |
492-11031
|
[12] |
LOCK WASHER,5/16"
|
CAS
WASHER, LOCK, 5/16" Superseded by part number: 83990583
|
| 3. |
700120268
|
[1] |
HOUSING
|
HFI
ASSEMBLY - pivot, left (Includes Item 4)
|
| 4. |
700709621
|
[1] |
SPHERICAL BEARING,31.78mm Hex x 72mm OD x 25mm W
|
CAS
BEARING - spherical (hex bore) Superseded by part number: 47442495
|
| 5. |
219-93
|
[2] |
LUBE NIPPLE,90 Degree Elbow, 1/4" - 28 NPTF
|
CAS
Superseded by part number: 87415
|
| 6. |
700709834
|
[1] |
ROLLER
|
HFI
- upper, tailgate
|
| 7. |
700120266
|
[1] |
HOUSING
|
HFI
ASSEMBLY - pivot, right (Includes Item 8)
|
| 8. |
1322251C91
|
[1] |
COLLAR
|
IH
BEARING - spherical Superseded by part number: 563733
|
