凯斯零件查询(8480) - CASE IH FIXED CHAMBER ROUND BALER (1/90-12/00) (3-02) - WINDGUARD AND MOUNTING ASSEMBLY Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
786 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700709453
|
[9] |
ROD
|
CAS
- windguard
|
| 2. |
700122914
|
[1] |
SUPPORT
|
HFI
- windguard
|
| 3. |
S120261
|
[2] |
PIN
|
CAS
HAIRPIN - cotter
|
| 4. |
413-612
|
[2] |
BOLT,Hex, 3/8" - 16 x 3/4", Gr 5
|
CAS
Superseded by part number: 72187204, 86500692
|
| 5. |
492-11038
|
[2] |
LOCK WASHER,3/8"
|
CAS
Superseded by part number: 80680, 72187249
|
| 6. |
425-106
|
[2] |
NUT,3/8"-16, Cl 5
|
CAS
Superseded by part number: 9628503
|
| 7. |
433-620
|
[9] |
CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 1 1/4", Gr 5
|
CAS
BOLT, CARRIAGE, Short NK, 3/8"-16 x 1 1/4", G5 Superseded by part number: 86508773
|
| 8. |
232-5316
|
[9] |
FLANGE NUT,Flg, 3/8"-16
|
CAS
3/8-16 HFTLN GR/G Superseded by part number: 86521609
|
| 9. |
700120300
|
[1] |
SUPPORT
|
HFI
- right
|
| 10. |
433-816
|
[4] |
CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 1", Gr 5
|
CAS
1/2-13 X 1 RHSNB Superseded by part number: 280486
|
| 11. |
231-5348
|
[4] |
FLANGE NUT,Flg, 1/2"-13
|
CAS
1/2-13 HFTLN GR/G Superseded by part number: 86521610
|
| 12. |
700120306
|
[2] |
PIN
|
HFI
|
| 13. |
700120299
|
[1] |
SUPPORT
|
HFI
- left
|
