凯斯零件查询(8480) - CASE IH FIXED CHAMBER ROUND BALER (1/90-12/00) (3-04) - PICKUP ASSEMBLY Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
678 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
565672R92
|
[2] |
SPHERICAL BEARING,1.2505" ID x 72 mm OD x 1"
|
IH
BEARING - spherical Superseded by part number: 84330041
|
| 2. |
T27207
|
[4] |
FLANGED BEARING
|
CAS
FLANGE - bearing Superseded by part number: 617863R1
|
| 3. |
700122908
|
[21] |
TINE
|
HFI
WRAPPER - tine
|
| 4. |
409-7512
|
[42] |
BOLT,Hex Flg, 5/16" - 18 x 3/4", Spcl
|
CAS
Hex Flg, 5/16-18 x 3/4", Serr Superseded by part number: 145913, 72187186
|
| 5. |
413-616
|
[3] |
BOLT,Hex, 3/8" - 16 x 1", Gr 5
|
CAS
Superseded by part number: 88206, 72187206
|
| 6. |
492-11038
|
[9] |
LOCK WASHER,3/8"
|
CAS
Superseded by part number: 80680, 72187249
|
| 7. |
700122954
|
[1] |
CAM
|
HFI
TRACK
|
| 8. |
95-81100
|
[6] |
WASHER,33/64" x 7/8" x .049"
|
CAS
1/2 X 18 GAUGE NRMB Superseded by part number: 86639334
|
| 9. |
413-624
|
[3] |
BOLT,Hex, 3/8" - 16 x 1-1/2", Gr 5
|
CAS
Superseded by part number: 72187209, 88044
|
| 10. |
425-106
|
[6] |
NUT,3/8"-16, Cl 5
|
CAS
Superseded by part number: 9628503
|
| 11. |
700120920
|
[1] |
FRAME
|
HFI
WA
|
| 12. |
434-616
|
[3] |
CARRIAGE BOLT,Sht Sq Nk, 3/8" - 16 x 1", Gr 5
|
CAS
3/8-16 X 1 RHSNB Superseded by part number: 80280503
|
