| 1. |
241-1315
|
[1] |
LINK, CONNECTING
|
CAS
CONNECTOR - link #50 R/C Superseded by part number: 87034815
|
| 2. |
1791D
|
[1] |
CHAIN (AG),#50, 192 Links x 15.88mm = 3048mm
|
IH
CHAIN - roller, #50 (10 foot bulk)
|
| 3. |
249-1
|
[1] |
KEY
|
IH
1/4 X 1-3/4 KEY - gib
|
| 4. |
700709425
|
[2] |
TIGHTENER
|
CAS
SLIDE - chain
|
| 5. |
700122958
|
[1] |
SPROCKET ASSY.
|
HFI
SPROCKET - 45 tooth (speed up)
|
| 6. |
433-672
|
[1] |
CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 4 1/2", Gr 5
|
CAS
3/8-16 X 4-1/2 RHSNB Superseded by part number: 280825
|
| 7. |
492-11038
|
[9] |
LOCK WASHER,3/8"
|
CAS
Superseded by part number: 80680, 72187249
|
| 8. |
425-106
|
[9] |
NUT,3/8"-16, Cl 5
|
CAS
Superseded by part number: 9628503
|
| 9. |
409-7512
|
[12] |
BOLT,Hex Flg, 5/16" - 18 x 3/4", Spcl
|
CAS
Hex Flg, 5/16-18 x 3/4", Serr Superseded by part number: 145913, 72187186
|
| 10. |
700120912
|
[1] |
DEFLECTOR
|
HFI
WA - left
|
| 11. |
700120913
|
[1] |
DEFLECTOR
|
HFI
WA - right
|
| 12. |
700122950
|
[3] |
PLATE
|
HFI
|
| 13. |
700122941
|
[2] |
PLATE
|
HFI
- pivot, pickup
|
| 14. |
700120902
|
[1] |
SPRING
|
HFI
ASSEMBLY (Includes Item 15)
|
| 15. |
700120868
|
[1] |
PLUG
|
HFI
- spring
|
| 16. |
7773385
|
[1] |
BOLT,Hex, 1/2" - 13 x 10", Gr 5, Full Thd
|
CAS
1/2-13 X 10 FTB
|
| 17. |
495-21056
|
[1] |
WASHER,1/2"
|
CAS
1/2 HARDENED PLAIN WASHER Superseded by part number: 72187265, 80700
|
| 18. |
425-108
|
[1] |
NUT,1/2" - 13, Gr 5
|
CAS
NUT, 1/2"-13, G5 Superseded by part number: 280431
|
| 19. |
413-616
|
[1] |
BOLT,Hex, 3/8" - 16 x 1", Gr 5
|
CAS
Superseded by part number: 88206, 72187206
|
| 20. |
231-4116
|
[1] |
NUT,3/8"-16, GB
|
CAS
3/8-16 HTLN GR/B Superseded by part number: 88902, E64197
|
| 21. |
700709632
|
[1] |
SPRING
|
CAS
|
| 22. |
700122964
|
[1] |
STOP
|
HFI
|
| 23. |
700122947
|
[1] |
SUPPORT
|
HFI
WA
|
| 24. |
413-1024
|
[1] |
BOLT,Hex, 5/8" - 11 x 1-1/2", Gr 5
|
CAS
Superseded by part number: 88062
|
| 25. |
396-21066
|
[1] |
WASHER,16.66mm ID x 33.33mm OD x 4.27mm Thk
|
CAS
- 5/8" bolt size 21/32" x 1 5/16" x .150", HDN Superseded by part number: 87613283
|
| 26. |
492-11062
|
[1] |
BEARING WASHER,5/8"
|
CAS
WASHER, LOCK, 5/8" Superseded by part number: 86729275
|
| 27. |
425-1010
|
[1] |
NUT,5/8"-11, G5
|
CAS
Superseded by part number: 280374
|
| 28. |
433-628
|
[8] |
CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 1 3/4", Gr 5
|
CAS
3/8-16 X 1-3/4 RHSNB Superseded by part number: 86508775
|
| 29. |
700106060
|
[1] |
SPACER
|
CAS
|
| 30. |
700126727
|
[1] |
SHIM
|
HFI
|
| 31. |
700710500
|
[1] |
SPROCKET ASSY.
|
CAS
SHIM SPROCKET - 17 tooth
|
| 32. |
Q3929
|
[1] |
KEY,Gib, 5/16" Sq x 1 1/2"
|
IH
5/16 X 1-1/2 KEY - gib
|
| 33. |
700122949
|
[1] |
SUPPORT
|
HFI
|
