| 1. |
111-360
|
[16] |
CARRIAGE BOLT,Short NK, 3/8"-16 x 3/4", G5
|
CAS
BOLT, CARRIAGE, Short NK, 3/8"-16 x 3/4", G5 Superseded by part number: 280430
|
| 2. |
492-11038
|
[16] |
LOCK WASHER,3/8"
|
CAS
Superseded by part number: 80680, 72187249
|
| 3. |
425-106
|
[16] |
NUT,3/8"-16, Cl 5
|
CAS
Superseded by part number: 9628503
|
| 4. |
700108622
|
[8] |
FLANGED BEARING
|
L
FLANGE - bearing
|
| 5. |
700122916
|
[1] |
ROTOR
|
HFI
WA
|
| 6. |
61-636
|
[4] |
HEX SOC SCREW,3/8"-16 x 2 1/4"
|
CAS
3/8-16 X 2-1/4 HSHCS SPL Superseded by part number: 61-33836
|
| 7. |
710392
|
[8] |
BEARING, ROLLER, CYL,27.33 mm ID x 47.09 mm OD x 25.4 mm
|
L
BEARING - spherical Superseded by part number: 84330047
|
| 8. |
700122922
|
[4] |
CRANK
|
HFI
WA
|
| 9. |
702700045
|
[4] |
LOCK NUT
|
L
1/2-20 SPIRALOCK NUT G8
|
| 10. |
700705612
|
[4] |
CAM FOLLOWER
|
L
BEARING - cam, follower Superseded by part number: 86536275
|
| 11. |
432-1632
|
[8] |
COTTER PIN,1/4" x 2"
|
CAS
Pin, Split (Cotter), 1/4" x 2" Superseded by part number: 88182
|
| 12. |
232-5316
|
[48] |
FLANGE NUT,Flg, 3/8"-16
|
CAS
3/8-16 HFTLN GR/G Superseded by part number: 86521609
|
| 13. |
700122920
|
[4] |
ANGLE
|
HFI
- tine, support
|
| 14. |
434-616
|
[44] |
CARRIAGE BOLT,Sht Sq Nk, 3/8" - 16 x 1", Gr 5
|
CAS
3/8-16 X 1 RHSNB Superseded by part number: 80280503
|
| 15. |
496-11041
|
[44] |
WASHER,13/32" x 13/16" x .065", HDN
|
CAS
3/8 HARDENED PLAIN WASHER Superseded by part number: 86632588
|
| 16. |
700709210
|
[44] |
TOOTH
|
L
TINE - double Superseded by part number: 47518553
|
| . . |
700714459
|
[44] |
TORSION SPRING,Coiled, 2 Prong, 203mm L
|
L
TINE - double Superseded by part number: 47518553
|
