凯斯零件查询(8480) - CASE IH FIXED CHAMBER ROUND BALER (1/90-12/00) (3-12) - RATCHET ASSEMBLY, SERIAL NUMBER CFH0051001 THROUGH CFH0051672 Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
683 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
052027
|
[1] |
RING, SNAP
|
CAS
SNAP - ring
|
| 2. |
700122957
|
[1] |
SPROCKET ASSY.
|
HFI
SPROCKET - 54 tooth (87 rpm)
|
| 3. |
6225759
|
[1] |
PAWL
|
CAS
|
| 4. |
219-8
|
[1] |
LUBE NIPPLE,1/4" - 28 NPTF
|
CAS
NIPPLE, LUBE, 1/4"-28 NPT x .54" lg Superseded by part number: 87414
|
| 5. |
6225742
|
[1] |
HUB
|
HFI
- ratchet
|
| 6. |
413-824
|
[2] |
BOLT,Hex, 1/2" - 13 x 1-1/2", Gr 5
|
CAS
Superseded by part number: 87689, 72187216
|
| 7. |
425-108
|
[2] |
NUT,1/2" - 13, Gr 5
|
CAS
NUT, 1/2"-13, G5 Superseded by part number: 280431
|
| 8. |
700710513
|
[1] |
SPRING
|
CAS
- leaf
|
| 9. |
495-21056
|
[1] |
WASHER,1/2"
|
CAS
1/2 HARDENED PLAIN WASHER Superseded by part number: 72187265, 80700
|
