凯斯零件查询(8480) - CASE IH FIXED CHAMBER ROUND BALER (1/90-12/00) (4-06) - CONSOLE CONTROL BOX MOUNTING ASSEMBLY Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
763 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700707295
|
[2] |
KNOB
|
CAS
- clamp
|
| 2. |
700114077
|
[1] |
SUPPORT
|
CAS
- control, box
|
| 3. |
51200165
|
[3] |
SCREW,Hex, 1/4"-20 x 1", G5
|
HFI
1/4-20 X 1 C
|
| 4. |
492-11025
|
[3] |
LOCK WASHER,1/4"
|
CAS
WASHER, LOCK, 1/4" Superseded by part number: 72187247, 80682
|
| 5. |
425-104
|
[3] |
NUT,1/4"-20, Cl 5
|
CAS
Superseded by part number: 7770, 72187220
|
| 6. |
700707294
|
[2] |
PUSH-ON NUT
|
CAS
WELL NUT - rubber Superseded by part number: 694147
|
