凯斯零件查询(8480) - CASE IH FIXED CHAMBER ROUND BALER (1/90-12/00) (4-08) - ACTUATOR ASSEMBLY, 700709661 ACTUATOR ASSEMBLY COMPLETE Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
431 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700709661
|
[1] |
ASSEMBLY
|
HFI
ACTUATOR - linear complete
|
| 2. |
700709904
|
[1] |
COVER
|
CAS
- tube
|
| 3. |
700709903
|
[1] |
SCREW
|
CAS
DRIVE SCREW ASSEMBLY
|
| 4. |
700704854
|
[1] |
HOUSING
|
HFI
- rear
|
| 5. |
1281485C1
|
[1] |
CLUTCH
|
IH
ASSEMBLY
|
| 6. |
91230C1
|
[1] |
GEAR
|
IH
- intermediate 20:1 (slow down)
|
| 7. |
1281484C1
|
[1] |
GEAR
|
IH
- intermediate 10:1
|
| 8. |
1281488C1
|
[1] |
HOUSING
|
IH
- front
|
| 9. |
700704871
|
[1] |
MOTOR, ELECTRIC
|
HFI
MOTOR - electric
|
| 10. |
1281489C1
|
[1] |
SEAL KIT
|
CAS
O-RING AND SEAL REPAIR KIT Includes items in art marked with asterisk
|
