凯斯零件查询(8480) - CASE IH FIXED CHAMBER ROUND BALER (1/90-12/00) (7-10) - SIDE AND PICKUP DRIVE SHIELD ASSEMBLIES, LEFT Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
330 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
121-115
|
[1] |
SERRATED BOLT,Hex, 5/16" - 18 x 3/4"
|
CAS
|
| 2. |
231-5145
|
[4] |
SERRATED NUT,Flg, USR, 5/16"-18
|
CAS
NUT, Flg, USR, 5/16"-18 Superseded by part number: 72187067, 145458
|
| 3. |
700711698
|
[2] |
DECAL
|
CAS
- slot, camloc
|
| 4. |
7895469
|
[2] |
STUD
|
CAS
OFFSET WING HEAD STUD
|
| 5. |
230-4218
|
[2] |
LOCK NUT,1/2"-13, GA
|
CAS
1/2-13 HCLN GR/B
|
| 6. |
495-21056
|
[2] |
WASHER,1/2"
|
CAS
1/2 HARDENED PLAIN WASHER Superseded by part number: 72187265, 80700
|
| 7. |
700120365
|
[1] |
SHIELD
|
HFI
- pickup drive
|
| 8. |
439-5532
|
[1] |
HEADED PIN,5/16" x 2"
|
CAS
5/16 X 2 CLEVIS PIN
|
| 9. |
700120348
|
[1] |
SHIELD
|
HFI
- front, left
|
| 10. |
700120366
|
[1] |
PANEL
|
HFI
- front, left
|
| 11. |
496-21034
|
[1] |
WASHER,11/32" x 11/16" x 0.89", HDN
|
CAS
Superseded by part number: 86637953
|
| 12. |
754606
|
[1] |
SPRING
|
CAS
- compression
|
| 13. |
256873
|
[3] |
BOLT,Hex Serr, 5/16" - 18 x 1/2", 5SPL, Full Thd
|
NH
|
| 14. |
S120261
|
[1] |
PIN
|
CAS
.148 WIRE HAIR PIN COTTER
|
| 15. |
432-812
|
[1] |
COTTER PIN,3/4" OAL x 1/8" W
|
CAS
PIN, SPLIT (COTTER), 1/8" x 3/4" Superseded by part number: 80756
|
| 16. |
700117067
|
[1] |
SUPPORT
|
CAS
- rod
|
| 17. |
794339
|
[2] |
SPRING WASHER
|
CAS
- special
|
| 18. |
700126723
|
[1] |
LATCH
|
HFI
- strap
|
