凯斯零件查询(8480) - CASE IH FIXED CHAMBER ROUND BALER (1/90-12/00) (6-02) - ROLLER SCRAPER AND BELT GUIDE ASSEMBLIES Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
865 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700120189
|
[5] |
SUPPORT
|
HFI
- scraper
|
| 2. |
433-512
|
[56] |
CARRIAGE BOLT,Sq Nk, 5/16" - 18 x 3/4", Gr 5
|
CAS
Superseded by part number: 280327
|
| 3. |
495-61034
|
[10] |
WASHER,0.34" ID x 0.88" OD x 0.06" Thk
|
CAS
5/16 WIDE PLAIN WASHER
|
| 4. |
492-11031
|
[100] |
LOCK WASHER,5/16"
|
CAS
WASHER, LOCK, 5/16" Superseded by part number: 83990583
|
| 5. |
425-105
|
[100] |
NUT,5/16"-18, G5
|
CAS
Superseded by part number: 9635082, 72187221
|
| 6. |
496-21034
|
[80] |
WASHER,11/32" x 11/16" x 0.89", HDN
|
CAS
Superseded by part number: 86637953
|
| 7. |
700120195
|
[5] |
GUIDE
|
HFI
|
| 8. |
700120187
|
[10] |
SCRAPER
|
HFI
|
| 9. |
433-520
|
[10] |
CARRIAGE BOLT,Sq Nk, 5/16" - 18 x 1 1/4", Gr 5
|
CAS
5/16-18 X 1-1/4 RHSNB Superseded by part number: 280507
|
| 10. |
700120190
|
[5] |
SUPPORT
|
HFI
- scraper
|
| 11. |
111-237
|
[34] |
CARRIAGE BOLT,Short NK, 5/16"-18 x 1", G5
|
CAS
BOLT, CARRIAGE, Short NK, 5/16"-18 x 1", G5 Superseded by part number: 33-516
|
| 12. |
700120193
|
[2] |
PLATE
|
HFI
|
