凯斯零件查询(8480) - CASE IH FIXED CHAMBER ROUND BALER (1/90-12/00) (6-04) - FORMING BELTS Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
409 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700709542
|
[5] |
BELT,279.40 mm W x 3079.75 mm L
|
CAS
Flat 279.40 mm W x 3079.75 mm L
|
| . . |
700711080
|
[5] |
BELT,279.40 mm W x 3079.75 mm L
|
CAS
Flat 279.40 mm W x 3079.75 mm L Superseded by part number: 700724730
|
| 2. |
700709544
|
[25] |
BELT,279.40 mm W x 1854.20 mm L
|
CAS
Forming 279.40 mm W x 1854.20 mm L
|
| . . |
700711079
|
[25] |
BELT,279.40 mm W x 1854.20 mm L
|
HFI
Forming 279.40 mm W x 1854.20 mm L Superseded by part number: 700724731
|
| 3. |
700711081
|
[1] |
PIN
|
CAS
- lacing (temporary replacement)
|
