凯斯零件查询(8610) - CASE IH BALE PROCESSOR (1/86-12/00) (2-06) - SUPPORT-U-JOINT ASSEMBLY Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
1009 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700136029
|
[1] |
MOUNTING PARTS
|
HFI
MOUNTING
|
| 2. |
700712616
|
[1] |
SPRING WASHER
|
CAS
- spring
|
| 3. |
700711557
|
[1] |
WASHER
|
CAS
1/2 HARDENED WIDE PLAIN WASHER
|
| 4. |
160-109
|
[1] |
BOLT,Hex, 1/2" - 13 x 1 3/4", Gr 8
|
CAS
1/2-13 X 1-3/4 HFS GR8
|
| 5. |
231-5348
|
[1] |
FLANGE NUT,Flg, 1/2"-13
|
CAS
1/2-13 HFTLN GR/G Superseded by part number: 86521610
|
| 6. |
700136030
|
[1] |
MOUNTING PARTS
|
HFI
SUPPORT
|
| 7. |
138-170
|
[1] |
LOCK PIN,3/8" x 1", Slotted
|
CAS
Pin, 3/8" x 1", Slotted
|
