神钢零件查询(6D15-T) - MITSUBISHI DIESEL ENGINE - K909 II & K909LC II EXCAVATORS (1/87-12/06) (01-015) - OIL COOLER Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
501 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1-11. | VAME074018 | [1] | COOLER ASSY. | KOBOIL COOLER ASSY |
| 1-7. | VAME034573 | [1] | COVER | KOBOIL COOLER COVER ASSY |
| 1. | VAME034572 | [1] | COVER | KOBCOVER,O/C |
| 2. | VAME034554 | [1] | PLUG | KOBPLUG,BY-PASS/V |
| 3. | VAME034700 | [1] | SPRING | KOBSPRING,BY-PASS/V |
| 4. | VAME034556 | [1] | VALVE | KOBVALVE,BY-PASS |
| 6. | VAMH035092 | [1] | O-RING | KOBO-RING 14 Superseded by part number: VA0550700140 |
| 7. | VAMH037117 | [3] | PLUG | KOBPLUG |
| . . | VAMH035044 | [3] | O-RING | KOBO-RING 18 Superseded by part number: 240098A1 |
| 8. | VAME074020 | [2] | ELEMENT | KOBELEMENT,0/C (4) |
| 9. | VAMF430006 | [4] | NUT | KOBNUT 10 Superseded by part number: VAF230510000 |
| . . | VAMF450406 | [4] | WASHER | KOBMASHER,SPG 10 |
| . . | VAMF450006 | [4] | NUT | KOBMASHER,PLAIN 10 Superseded by part number: 133247A1 |
| 10. | VAMH035091 | [2] | O-RING | KOBO-RING |
| 11. | VAMH035092 | [4] | O-RING | KOBO-RING Superseded by part number: VA0550700140 |
| 12. | VAMH035094 | [3] | O-RING | KOBO-RING |
| 13. | VAME034031 | [1] | GASKET | KOBGASKET Superseded by part number: 77269118, VAME074293 |
| 14. | VAMF140226 | [23] | SCREW | KOBBOLT.FLANGE 8X22 |
