凯斯零件查询(8610) - CASE IH BALE PROCESSOR (1/86-12/00) (8-16) - CYLINDER HYDRAULIC TILT ASSEMBLY, 2-1/2 INCH BORE X 16 INCH STROKE, S/N CFH0036001 THRU CFH0036201 Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
487 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . . |
700704318
|
[1] |
CYLINDER
|
HFI
- hydraulic assembly complete (2-1/2 inch bore x 16 inch stroke) Superseded by part number: 700712023
|
| 1. |
700704925
|
[2] |
CLEVIS PIN
|
IH
PIN - clevis Superseded by part number: 102910A1
|
| 2. |
700704894
|
[1] |
CYLINDER HEAD
|
CAS
HEAD WITH CLEVIS
|
| 3. |
S120261
|
[2] |
PIN
|
CAS
.148 WIRE HAIR PIN COTTER
|
| 4. |
102909A1
|
[1] |
BEARING
|
CAS
BARREL
|
| . . |
700710239
|
[1] |
TUBE ASSY.
|
CAS
BARREL Superseded by part number: 700712116, 102909A1
|
| 5. |
700704892
|
[1] |
PISTON
|
CAS
- cylinder (Sub. 700710191 piston and 700710192 seal and O-Ring repair kit) Superseded by part number: H673838, 102905A1
|
| . . |
102905A1
|
[1] |
PISTON
|
CAS
- cylinder
|
| . . |
H673838
|
[1] |
SEAL
|
CAS
SEAL AND O-RING KIT
|
| 6. |
700704921
|
[1] |
ROD
|
HFI
- piston
|
| 7. |
700704891
|
[1] |
CYLINDER END CAP
|
CAS
BEARING - cylinder rod
|
| 8. |
700704920
|
[1] |
ROD ASSY.
|
HFI
CLEVIS - rod end
|
| 9. |
700705922
|
[1] |
ORIFICE
|
HFI
|
