凯斯零件查询(8610) - CASE IH BALE PROCESSOR (1/86-12/00) (8-18) - CYLINDER HYDRAULIC TILT ASSEMBLY, 3 INCH BORE X 16 INCH STROKE, SERIAL NUMBER CFH0036202 AND LATER Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
899 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . . |
700709525
|
[1] |
CYLINDER,Double Acting, 31.75mm Rod, 406.4mm Stroke
|
CAS
- hydraulic assembly complete (3 inch bore x 16 inch stroke)
|
| 1. |
B17274
|
[1] |
PISTON
|
CAS
|
| 2. |
131-909
|
[1] |
LOCK NUT,3/4"-16
|
CAS
NUT - piston
|
| 3. |
700709538
|
[1] |
TUBE
|
CAS
BARREL
|
| 4. |
700708462
|
[1] |
ORIFICE
|
CAS
Superseded by part number: 849287
|
| 5. |
700709534
|
[1] |
BASE
|
CAS
- clevis
|
| 6. |
S120261
|
[2] |
PIN
|
CAS
.149 X 2-3/4 HAIRPIN COTTER
|
| 7. |
811134C1
|
[2] |
PIN
|
IH
- clevis Superseded by part number: 427-16350
|
| 8. |
700709537
|
[1] |
ROD
|
CAS
|
| 9. |
700709536
|
[4] |
ROD
|
CAS
TIE ROD
|
| 10. |
812166C2
|
[1] |
END
|
CAS
HEAD
|
| 11. |
T55022
|
[1] |
CLEVIS
|
CAS
- rod
|
| 12. |
B17231
|
[1] |
KIT
|
CAS
SEAL KIT
|
