凯斯零件查询(8610) - CASE IH BALE PROCESSOR (1/86-12/00) (8-22) - CYLINDER HYDRAULIC ASSEMBLY, 700708083 CYLINDER HYDRAULIC ASSEMBLY COMPLETE, 3" BORE X 16" STROKE Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
694 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . . |
700708083
|
[1] |
CYLINDER
|
CAS
- hydraulic assembly complete (3 inch bore x 16 inch stroke) Superseded by part number: 700712024
|
| 1. |
700704925
|
[2] |
CLEVIS PIN
|
IH
PIN - clevis Superseded by part number: 102910A1
|
| 2. |
700700105
|
[1] |
HEAD
|
CAS
WITH CLEVIS
|
| 3. |
S120261
|
[2] |
PIN
|
CAS
.148 WIRE HAIR PIN COTTER
|
| 4. |
700708459
|
[1] |
TUBE ASSY.
|
CAS
BARREL - cylinder Superseded by part number: 102683A1, 102686A1
|
| . . |
700710261
|
[1] |
TUBE ASSY.
|
CAS
BARREL (Ends of I.D. are chamfered for O-Ring repair kit) Superseded by part number: 102686A1, 102683A1
|
| 5. |
700707145
|
[1] |
PISTON
|
CAS
- cylinder (Sub. 700710259 piston and 700710260 seal and O-Ring repair kit) Superseded by part number: 102682A1, 700710260
|
| . . |
H436684
|
[1] |
JACK PISTON
|
CAS
PISTON - cylinder Superseded by part number: 102682A1
|
| . . |
700710260
|
[1] |
SEAL KIT
|
CAS
AND O-RING KIT
|
| 6. |
700708458
|
[1] |
ROD
|
CAS
- piston
|
| 7. |
700707144
|
[1] |
BUSHING
|
CAS
BEARING - cylinder rod Superseded by part number: 102690A1, 102686A1
|
| 8. |
700708460
|
[1] |
END
|
CAS
CLEVIS - rod end
|
| 9. |
700708462
|
[1] |
ORIFICE
|
CAS
Superseded by part number: 849287
|
| 10. |
700704850
|
[1] |
SEAL KIT
|
CAS
SEAL AND O-RING REPAIR KIT
|
