神钢零件查询(6D15-T) - MITSUBISHI DIESEL ENGINE - K909 II & K909LC II EXCAVATORS (1/87-12/06) (03-007) - ALTERNATOR (INNER PARTS) Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
263 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1-22. | VAME070120 | [1] | ALTERNATOR | KOBALTERNATOR ASSY 24V-30A,FOR M1 ONLY |
| . . | 6D160WT-KS12 | [1] | ALTERNATOR (INNER PARTS)(M6) | |
| . . | 6D152CT-YJ01 | [1] | ALTERNATOR (INNER PARTS)(M1) | |
| 1. | VAME700588 | [1] | NUT | KOBHUT SET,FOR M1 ONLY Superseded by part number: 135142A1 |
| 1-22. | VAME049173 | [1] | ALTERNATOR | KOBALTERNATOR ASSY 24V-40A,FOR M6 ONLY |
| 2. | VAHE700589 | [1] | PULLEY BX2,FOR M1 ONLY | |
| 3. | VAME700590 | [1] | SCREW SET SCREW SET | SCREW SET SCREW SET |
| . . | VAME700609 | [1] | PULLEY BX2,FOR M6 ONLY | |
| 4-6. | VAME700633 | [1] | PANEL | KOBBRACKET ASSY.FR,FOR M1 ONLY |
| 4. | NSS | [1] | NOT SOLD SEPARAT | CONBRACKET.FR |
| . . | VAME700648 | [1] | BKT ASSY BRACKET ASSY.FR,FOR M6 ONLY | BKT ASSY BRACKET ASSY.FR,FOR M6 ONLY |
| 5. | VAMM502367 | [1] | SCREW SCREU SET | SCREW SCREU SET |
| 6. | VAME700535 | [1] | BEARING | KOBBEARING.FR Superseded by part number: VAS930P37201, VAS930P37270 |
| 7-8. | VAME700666 | [1] | ROTOR ASSY,FOR M1 ONLY | |
| 7. | NSS | [1] | NOT SOLD SEPARAT | CONROTOR |
| . . | VAME700611 | [1] | ROTOR | KOBROTOR ASSY,FOR M6 ONLY |
| 8. | VAME700746 | [1] | BALL BEARING | KOBBEARING,RE Superseded by part number: VAS930P80870 |
| 13. | VAME700607 | [1] | STATOR | KOBSTATOR,FOR M1 ONLY |
| 14-22. | VAME700766 | [1] | U-BRACKET | KOBBRACKET ASSY,RE,FOR M1 ONLY |
| 13. | VAME700612 | [1] | STATOR | KOBSTATOR,FOR M6 ONLY |
| 14. | NSS | [1] | NOT SOLD SEPARAT | CONBRACKET,RE |
| 14-22. | VAME700824 | [1] | BRACKET | KOBBRACKET ASSY,FOR M6 ONLY |
| 15A. | VAME700596 | [1] | TERMINAL | KOBTERMINAL SET,FOR M1 ONLY |
| 16A. | VAME700639 | [1] | HYD CONNECTOR | KOBCONNECTOR ASSY Superseded by part number: VAA309D11271, 77269928 |
| 15A. | VAME700614 | [1] | TERMINAL SET,FOR M6 ONLY | |
| 16B. | VAME700154 | [1] | BOLT BOLT | BOLT BOLT |
| 17. | VAME700821 | [1] | NUT | KOBNUT SET,FOR M1 ONLY |
| 19. | VAME700767 | [1] | RECTIFIER | KOBRECTIFIRE ASSY,FOR M1 ONLY |
| 17. | VAMD607499 | [1] | BOLT AND NUT | KOBNUT SET,FOR M6 ONLY |
| 19. | VAME700850 | [1] | RECTIFIER | KOBRECTIFIRE ASSY,FOR M6 ONLY Superseded by part number: VAA860T22470 |
| 20. | NSS | [1] | NOT SOLD SEPARAT | CONREGULATOR |
| 20-22. | VAME700635 | [1] | REGULATOR | KOBREGULATOR ASSY Superseded by part number: VAA866T06870 |
| 21. | VAMM502377 | [2] | BRUSH | KOBBRUSH |
| 22. | VAMM502378 | [2] | SPRING SPRING,BRUSH | SPRING SPRING,BRUSH |
