| 1. |
700709385
|
[1] |
JACK
|
IH
(Incl. items 2, 3 & 4)
|
| 2. |
700702060
|
[1] |
CRANKED HANDLE
|
CAS
CRANK KIT
|
| 3. |
700702059
|
[1] |
KIT
|
CAS
GEAR SET Superseded by part number: 86590811
|
| 4. |
700709409
|
[1] |
LINK CHAIN
|
CAS
PIN AND CHAIN ASSEMBLY
|
| 5. |
413-10104
|
[1] |
BOLT,Hex, 5/8" - 11 x 6-1/2", Gr 5
|
CAS
Superseded by part number: 86507000
|
| 6. |
232-53110
|
[6] |
FLANGE NUT,Flg, 5/8"-11
|
CAS
5/8-11 HFTLN GR/G Superseded by part number: 84180923
|
| 7. |
413-1088
|
[1] |
BOLT,Hex, 5/8" - 11 x 5-1/2", Gr 5
|
CAS
5/8-11 X 5-1/2 C Superseded by part number: 280232
|
| 8. |
6561351
|
[1] |
CAP WASHER
|
CAS
|
| 9. |
700105398
|
[1] |
SPACER
|
HFI
|
| 10. |
700117348
|
[1] |
PLATE
|
HFI
- reinf, lower
|
| 11. |
700705598
|
[1] |
CHAIN (CE)
|
CAS
CHAIN - safety
|
| 12. |
700117987
|
[1] |
STOP
|
HFI
LOOP - safety chain
|
| 13. |
6549547
|
[2] |
SPACER
|
HFI
|
| 14. |
700117628
|
[2] |
WEDGE
|
HFI
|
| 15. |
700117360
|
[1] |
PLATE
|
HFI
- hitch, lower
|
| 16. |
360-816
|
[8] |
BOLT,Hex, 1/2" - 13 x 1", Gr 8
|
CAS
1/2-13 X 1 HFS GR8 Superseded by part number: 87034823
|
| 17. |
231-5348
|
[13] |
FLANGE NUT,Flg, 1/2"-13
|
CAS
1/2-13 HFTLN GR/G Superseded by part number: 86521610
|
| 18. |
413-1044
|
[2] |
BOLT,Hex, 5/8" - 11 x 2-3/4", Gr 5
|
CAS
5/8-11 X 2-3/4 C Superseded by part number: 88693
|
| 19. |
413-1032
|
[2] |
BOLT,Hex, 5/8" - 11 x 2", Gr 5
|
CAS
C Hex, 5/8"-11 x 2", G5 Superseded by part number: 86505999
|
| 20. |
700117361
|
[1] |
PLATE
|
HFI
- reinf, top
|
| 21. |
433-816
|
[1] |
CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 1", Gr 5
|
CAS
1/2-13 X 1 RHSNB Superseded by part number: 280486
|
| 22. |
433-824
|
[2] |
CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 1 1/2", Gr 5
|
CAS
1/2-13 X 1-1/2 RHSNB Superseded by part number: 280420, 72187237
|
| 23. |
700117362
|
[1] |
SUPPORT
|
HFI
|
| 24. |
433-820
|
[2] |
CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 1 1/4", Gr 5
|
CAS
1/2-13 X 1-1/4 RHSNB Superseded by part number: 87868
|
| 25. |
700108873
|
[1] |
ANCHOR
|
HFI
MOUNTING WA - jack
|
