凯斯零件查询(8610) - CASE IH BALE PROCESSOR (1/86-12/00) (3-4) - WHEEL AND HUB ASSEMBLY Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
867 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
T52730
|
[6] |
WHEEL BOLT
|
IH
9/16-18 X 1-1/8 WHEEL BOLT Superseded by part number: 86628557
|
| 2. |
D143405
|
[1] |
CAP
|
CAS
- hub Superseded by part number: 137395
|
| 3. |
A57879
|
[1] |
RIM
|
CAS
WHEEL - 15" x 8 (Standard tire)
|
| . . |
700707982
|
[1] |
RIM
|
CAS
WHEEL - 15" x 10L (Flotation tire) Superseded by part number: 10110254
|
| 4. |
432-824
|
[1] |
COTTER PIN,1/8" x 1 1/2"
|
CAS
PIN, SPLIT (COTTER), 1/8" x 1-1/2" Superseded by part number: 80708
|
| 5. |
165964R1
|
[1] |
BEARING CUP
|
IH
CUP - bearing, outer Superseded by part number: 86516462
|
| 6. |
130503H
|
[1] |
BEARING CUP
|
IH
CUP - bearing, inner Superseded by part number: 86900365
|
| 7. |
026690
|
[1] |
HUB
|
CAS
ASSEMBLY (Includes items 5 & 6)
|
| 8. |
300426R91
|
[1] |
BEARING ASSY,45.618 mm ID x 25.4 mm
|
IH
CONE - bearing, inner Superseded by part number: 512725
|
| 9. |
491715R91
|
[1] |
OIL SEAL
|
IH
|
| 10. |
6546345
|
[1] |
SPINDLE
|
HFI
|
| 11. |
560953R91
|
[1] |
BEARING ASSY,1.375" ID x 2.875" OD x 0.9688"
|
IH
CONE - bearing, outer Superseded by part number: 86516471
|
| 12. |
26971
|
[1] |
WASHER
|
CAS
|
| 13. |
425-1314
|
[1] |
SLOTTED NUT,7/8"-14, G5
|
CAS
7/8-14 SLOTTED HEX NUT Superseded by part number: 84151573
|
| 14. |
A38261
|
[1] |
VALVE
|
CAS
STEM - valve (Flotation) Superseded by part number: 196033
|
| 15. |
827253
|
[1] |
TYRE/TIRE
|
HFI
TIRE - flotation 12.5 x 15 Superseded by part number: 84994779
|
