凯斯零件查询(8610) - CASE IH BALE PROCESSOR (1/86-12/00) (5-08) - ROTOR ASSEMBLY Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
712 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
7852148
|
[2] |
RING, SNAP
|
IH
SNAP RING
|
| 2. |
413-1220
|
[2] |
BOLT,Hex, 3/4" - 10 x 1-1/4", Gr 5
|
CAS
3/4-10 X 1-1/4 C Superseded by part number: 88691
|
| 3. |
232-53112
|
[2] |
FLANGE NUT,Flg, 3/4"-10
|
CAS
3/4-10 HFTLN GR/G Superseded by part number: 86512372
|
| 4. |
700108823
|
[15] |
DISC
|
HFI
- rotor
|
| 5. |
433-820
|
[8] |
CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 1 1/4", Gr 5
|
CAS
1/2-13 X 1-1/4 RHSNB Superseded by part number: 87868
|
| 6. |
231-5348
|
[8] |
FLANGE NUT,Flg, 1/2"-13
|
CAS
1/2-13 HFTLN GR/G Superseded by part number: 86521610
|
| 7. |
700114457
|
[8] |
WEDGE
|
IH
|
| 8. |
700109915
|
[3] |
WASHER
|
IH
WASHER - square
|
| 9. |
700108822
|
[2] |
DISC
|
HFI
- end
|
| 10. |
700115850
|
[35] |
SPACER
|
IH
|
| 11. |
705566
|
[4] |
WASHER
|
IH
3/4 HARDENED PLAIN WASHER
|
| 12. |
700115849
|
[1] |
SHAFT
|
HFI
- rotor
|
| 13. |
19329R1
|
[24] |
LOCK PIN,5/32" x 1 1/2", Slotted
|
IH
5/32 X 1 SLOTTED SPRING PIN Superseded by part number: 70923740
|
| 14. |
700108838
|
[12] |
ROD
|
IH
- blade
|
| 15. |
700118640
|
[7] |
KNIFE
|
IH
KIT - blade, rotor (Set of 2 blades)
|
