| 1. |
61747
|
[1] |
KEY
|
CAS
1/2 X 1/2 X 2-1/2 GIB KEY
|
| 2. |
700117329
|
[1] |
BRAKE
|
HFI
DISC - brake
|
| 3. |
714360
|
[1] |
FLANGED BEARING
|
IH
FLANGE - bearing, inner
|
| 4. |
712158
|
[1] |
SPHERICAL BEARING,2" ID x 100 mm OD
|
L
BEARING - spherical Superseded by part number: 47577203
|
| 5. |
700118628
|
[1] |
FLANGE
|
IH
- bearing
|
| 6. |
700117372
|
[1] |
PANEL
|
HFI
- end, rotor
|
| 7. |
433-820
|
[7] |
CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 1 1/4", Gr 5
|
CAS
1/2-13 X 1-1/4 RHSNB Superseded by part number: 87868
|
| 8. |
231-5348
|
[17] |
FLANGE NUT,Flg, 1/2"-13
|
CAS
1/2-13 HFTLN GR/G Superseded by part number: 86521610
|
| 9. |
433-824
|
[6] |
CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 1 1/2", Gr 5
|
CAS
1/2-13 X 1-1/2 RHSNB Superseded by part number: 280420, 72187237
|
| 10. |
51200285
|
[1] |
SCREW
|
CAS
3/8-16 X 7 EYEBOLT
|
| 11. |
R31412
|
[1] |
SPRING
|
CAS
- extension
|
| 12. |
425-106
|
[3] |
NUT,3/8"-16, Cl 5
|
CAS
Superseded by part number: 9628503
|
| 13. |
496-11041
|
[2] |
WASHER,13/32" x 13/16" x .065", HDN
|
CAS
3/8 HARDENED PLAIN WASHER Superseded by part number: 86632588
|
| 14. |
700117591
|
[1] |
PIVOT
|
HFI
ARM - pivot, brake
|
| 15. |
700117594
|
[1] |
MOUNTING PARTS
|
HFI
SUPPORT - brake
|
| 16. |
700708796
|
[1] |
CALIPER
|
CAS
BRAKE - disc, caliper
|
| 17. |
700708805
|
[1] |
KIT
|
IH
- lining repair, brake Superseded by part number: H378463
|
| 18. |
6865851
|
[1] |
SPACER
|
HFI
|
| 19. |
496-11028
|
[2] |
WASHER,9/32" x 5/8" x .065, HDN
|
CAS
1/4 HARDENED PLAIN WASHER Superseded by part number: 86632587
|
| 20. |
432-612
|
[2] |
COTTER PIN,3/32" x 3/4"
|
CAS
PIN , SPLIT (COTTER), 3/32" x 3/4" Superseded by part number: 280250
|
| 21. |
700117595
|
[1] |
ROD
|
HFI
- linkage, brake
|
| 22. |
413-824
|
[2] |
BOLT,Hex, 1/2" - 13 x 1-1/2", Gr 5
|
CAS
Superseded by part number: 87689, 72187216
|
| 23. |
705541
|
[9] |
WASHER,0.53" ID x 1.06" OD x 0.14" Thk
|
CAS
1/2 HARDENED PLAIN WASHER
|
| 24. |
700122793
|
[2] |
SHIELD
|
HFI
- rotor
|
| 25. |
413-828
|
[1] |
BOLT,Hex, 1/2" - 13 x 1-3/4", Gr 5
|
CAS
Superseded by part number: 9707516, 72187217
|
