神钢零件查询(6D15-T) - MITSUBISHI DIESEL ENGINE - K909 II & K909LC II EXCAVATORS (1/87-12/06) (07-001) - CYLINDER BLOCK REPAIR KIT Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
896 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1-25. | VAME999916 | [1] | CRANKCASE ASSY CRANKCASE ASSY 6D15.15T | CRANKCASE ASSY CRANKCASE ASSY 6D15.15T |
| 1. | VAME071221 | [1] | CRANKCASE | |
| 2. | VAME031914 | [6] | CAP CAP.BRG FR & MI | CAP CAP.BRG FR & MI |
| 3. | VAME031915 | [1] | CAP,BRG RE | |
| 4. | VAME031865 | [14] | SCREW | KOBBOLT 14X106 |
| 5. | VAME071064 | [6] | LINER, ENGINE CYLIND | KOBLINER,CYL B SIZE |
| 6. | VAME031610 | [12] | O-RING | KOBO-RIHO |
| 7. | VAHE071066 | [6] | PACKING | |
| 8. | VAMH012041 | [6] | PIN | KOBPIN,SPG 4X10 |
| 9. | VAMH037137 | [2] | PLUG | KOBPLUG 20 |
| . . | VAMF660068 | [2] | PACKING | KOBGASKET 20 Superseded by part number: VAF420220000 |
| 12. | VAMH007011 | [1] | PIN | KOBPIN,DOWEL 12X34 Superseded by part number: 132324A1 |
| 13. | VAMF645535 | [1] | CAP,SEALING 18 | |
| 14. | VAMH007010 | [1] | PIN | KOBPIN,DOWEL 12X17 |
| 15. | VAMF472404 | [2] | DOWEL | KOBPIN,DOWEL 8X18 Superseded by part number: MF472404 |
| 16. | VAMH037082 | [2] | PLUG PLUG 6.5X8 | PLUG PLUG 6.5X8 |
| 17. | VAME071141 | [1] | BUSHING | KOBBUSHING,CAMSHAFT NO.1 |
| 18. | VAHE071142 | [1] | BUSHING,CAMSHAFT NO.2 | |
| 19. | VAME071143 | [1] | BUSHING | KOBBUSHING,CAMSHAFT NO.3 |
| 20. | VAME071144 | [1] | BUSHING | KOBBUSHING,CAMSHAFT NO.4 Superseded by part number: VAME071862 |
| 21. | VAME031087 | [1] | SET OF SCREWS | KOBSCREW,SET |
| . . | VAMF660063 | [1] | GASKET | KOBGASKET 10 Superseded by part number: VAF420210000 |
| 21A. | VAME031087 | [1] | SET OF SCREWS | KOBSCREW,SET(WITHOUT VACCUM PUMP) |
| 24. | VAME031088 | [1] | PLUG | KOBPLUG |
| 25. | VAMS666222 | [1] | PLUG | SMPLUG,TAPER PT3/8(WITHOUT VACCUM PUMP) |
