凯斯零件查询(8610) - CASE IH BALE PROCESSOR (1/86-12/00) (7-08) - GRID ASSEMBLY Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
269 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700117324
|
[1] |
SUPPORT
|
IH
GRID - high
|
| 2. |
700117323
|
[2] |
SUPPORT
|
IH
GRID - lower
|
| 3. |
433-820
|
[12] |
CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 1 1/4", Gr 5
|
CAS
1/2-13 X 1-1/4 RHSNB Superseded by part number: 87868
|
| 4. |
231-5348
|
[12] |
FLANGE NUT,Flg, 1/2"-13
|
CAS
1/2-13 HFTLN GR/G Superseded by part number: 86521610
|
| 5. |
433-1024
|
[19] |
CARRIAGE BOLT,Sq Nk, 5/8" - 11 x 1 1/2", Gr 5
|
CAS
5/8-11 X 1-1/2 RHSNB Superseded by part number: 280832
|
| 6. |
232-53110
|
[19] |
FLANGE NUT,Flg, 5/8"-11
|
CAS
5/8-11 HFTLN GR/G Superseded by part number: 84180923
|
| 7. |
700117327
|
[1] |
LARGE PLATE
|
IH
PLATE - grid
|
| 8. |
700117326
|
[9] |
MOUNTING PARTS
|
IH
ANGLE - mounting
|
| 9. |
700124957
|
[1] |
BAR
|
HFI
- reinforcement
|
