| 1. |
38-11624
|
[4] |
LOCK PIN,1/4" x 1 1/2", Slotted
|
CAS
PIN, 1/4" x 1 1/2", Slotted Superseded by part number: 87406
|
| 2. |
700117631
|
[2] |
PIN
|
CAS
|
| 3. |
434-616
|
[18] |
CARRIAGE BOLT,Sht Sq Nk, 3/8" - 16 x 1", Gr 5
|
CAS
3/8-16 X 1 RHSNB Superseded by part number: 80280503
|
| 4. |
232-5316
|
[22] |
FLANGE NUT,Flg, 3/8"-16
|
CAS
3/8-16 HFTLN GR/G Superseded by part number: 86521609
|
| 5. |
433-824
|
[14] |
CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 1 1/2", Gr 5
|
CAS
1/2-13 X 1-1/2 RHSNB Superseded by part number: 280420, 72187237
|
| 6. |
231-5348
|
[22] |
FLANGE NUT,Flg, 1/2"-13
|
CAS
1/2-13 HFTLN GR/G Superseded by part number: 86521610
|
| 7. |
700124866
|
[8] |
SEGMENT
|
HFI
SPROCKET (Segment replacement of 28 teeth)
|
| 8. |
700115834
|
[1] |
STRAP
|
HFI
- adjustable
|
| 9. |
433-828
|
[2] |
CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 1 3/4", Gr 5
|
CAS
1/2-13 X 1-3/4 RHSNB Superseded by part number: 88530
|
| 10. |
433-620
|
[4] |
CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 1 1/4", Gr 5
|
CAS
BOLT, CARRIAGE, Short NK, 3/8"-16 x 1 1/4", G5 Superseded by part number: 86508773
|
| 11. |
700117319
|
[1] |
BLOCK DRIVER
|
HFI
DRIVER - fixed
|
| 12. |
700117313
|
[2] |
ARM
|
HFI
- driver, bale
|
| 13. |
7870132
|
[4] |
BOLT,Sq Nk, 5/8" - 11 x 1 1/4", Gr 5
|
CAS
5/8-11 X 1-1/4 RHSNB
|
| 14. |
232-53110
|
[8] |
FLANGE NUT,Flg, 5/8"-11
|
CAS
5/8-11 HFTLN GR/G Superseded by part number: 84180923
|
| 15. |
700117632
|
[4] |
PLATE
|
HFI
- backup
|
| 16. |
700117318
|
[2] |
PLATE
|
HFI
- stop
|
| 17. |
433-1024
|
[4] |
CARRIAGE BOLT,Sq Nk, 5/8" - 11 x 1 1/2", Gr 5
|
CAS
5/8-11 X 1-1/2 RHSNB Superseded by part number: 280832
|
| 18. |
413-896
|
[2] |
BOLT,Hex, 1/2" - 13 x 6", Gr 5
|
CAS
1/2-13 X 6 C Superseded by part number: 86000020
|
| 19. |
705541
|
[4] |
WASHER,0.53" ID x 1.06" OD x 0.14" Thk
|
CAS
1/2 HARDENED PLAIN WASHER
|
| 20. |
413-8120
|
[2] |
BOLT,Hex, 1/2" - 13 x 7-1/2", Gr 5
|
CAS
1/2-13 X 7-1/2 B Superseded by part number: 86505997
|
| 21. |
413-888
|
[2] |
BOLT,Hex, 1/2" - 13 x 5-1/2", Gr 5
|
CAS
.5 X 5.5 UNC GR5 YZD Superseded by part number: 88576
|
| 22. |
700118643
|
[2] |
TINE
|
HFI
|
