凯斯零件查询(8610) - CASE IH BALE PROCESSOR (1/86-12/00) (7-14) - ROLLER CONTAINER CARRIER ASSEMBLY Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
413 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700117311
|
[1] |
SUPPORT
|
HFI
BRACKET - support
|
| 2. |
7713829
|
[1] |
BEARING ASSY,19.56 mm ID x 63.75 mm OD
|
IH
- cam Superseded by part number: 688282
|
| 3. |
396-21066
|
[1] |
WASHER,16.66mm ID x 33.33mm OD x 4.27mm Thk
|
CAS
- 5/8" bolt size 21/32" x 1 5/16" x .150", HDN Superseded by part number: 87613283
|
| 4. |
667925R91
|
[1] |
ROLLER BEARING,0.628" ID x 2" OD x 15 mm
|
IH
- cam Superseded by part number: 47577176
|
| 5. |
700711165
|
[1] |
WASHER,17.3mm ID x 45.21mm OD x 4.06mm Thk
|
CAS
5/8 HARDENED WIDE PLAIN WASHER
|
| 6. |
413-1032
|
[1] |
BOLT,Hex, 5/8" - 11 x 2", Gr 5
|
CAS
C Hex, 5/8"-11 x 2", G5 Superseded by part number: 86505999
|
| 7. |
232-53110
|
[1] |
FLANGE NUT,Flg, 5/8"-11
|
CAS
5/8-11 HFTLN GR/G Superseded by part number: 84180923
|
| 8. |
7775067
|
[1] |
FLANGE NUT,Flg, 3/4"-16, G8
|
HFI
3/4-16 HFTLN GRG Superseded by part number: 9790660
|
