神钢零件查询(6D15-T) - MITSUBISHI DIESEL ENGINE - K909 II & K909LC II EXCAVATORS (1/87-12/06) (02-001) - FUEL INJECTION PUMP GENERAL Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
872 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 15CTYJ01-511 | [1] | FUEL INJECTION PUMP,GENERAL | |
| . . | 6D152CY-YJ01 | [1] | FUEL INJECTION PUMP,GENERAL | |
| 1-5. | VAME070761 | [1] | CORE-INJECTION PUMP | KOBINJECTION PUMP,FOR F2 ONLY(DKC 1016021110) |
| 1-5. | VAME070760 | [1] | FUEL INJECTION PUMP | KOBGENERL ASSY,FOR F1 ONLY(DKC 1016021100) |
| 1. | NSS | [1] | NOT SOLD SEPARAT | CONINJECTION PUMP ASSY A TYPE(CF GN040-131C),OEM PART NO:ME723427 |
| 2. | VAME716986 | [1] | GOVERNOR ASSY RS.V TYPE,FOR F2 ONLY(CF GN040-132C) | |
| 2. | VAME723244 | [1] | GOVERNOR, AS RSV TYPE,FOR F1 ONLY(CF GN040-132C) | GOVERNOR, AS RSV TYPE,FOR F1 ONLY(CF GN040-132C) |
| 3. | VAME036005 | [1] | PUMP | KOBFUEL FEED PUHP ASSY KE TYPE(CF GN040-133C)(DKC 1052104640) Superseded by part number: VAME717109 |
| 5. | VAME723426 | [1] | COUPLING | KOBC0UPLING(CF GN040-135B) |
| 7. | VAME035679 | [1] | CLUTCH DISC | KOBCLUTCH DISK DISK.DRIVING Superseded by part number: VAME076553 |
| 8. | VAMH035500 | [1] | O-RING | KOBO-RING 14 |
| 9. | VAME047182 | [1] | STAY | KOBSTAY.I/P |
| 10. | VAMF140223 | [2] | BOLT | KOBBOLT.FLANGE 8X16 |
| 11. | VAMH005068 | [2] | WASHER | KOBMASHER,PLAIN 10 |
| 14. | VAMF434105 | [4] | NUT | KOBNUT,FLANGE 10 |
| 15. | VAMF434105 | [1] | NUT | KOBNUT,FLANGE 10 |
| 16. | VA3186090600 | [1] | LEVER | KOBLEVER.STOP,FOR F1 ONLY |
| 17. | VAMF140207 | [1] | SHOCK ABSORBER BOLT,FLANGE 6X20,FOR F1 ONLY | SHOCK ABSORBER BOLT,FLANGE 6X20,FOR F1 ONLY |
| . . | VAMF434103 | [1] | NUT | KOBNUT,FLANGE 6,FOR F1 ONLY |
