神钢零件查询(6D15-T) - MITSUBISHI DIESEL ENGINE - K909 II & K909LC II EXCAVATORS (1/87-12/06) (02-002) - FUEL INJECTION PUMP GENERAL Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
940 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 6D160WT-KS12 | [1] | FUEL INJECTION PUMP GENERAL | |
| 1-6. | VAME047493 | [1] | INJECTIONPUMP GENERAL ASSY(DKC 1016061480) | |
| 1. | NSS | [1] | NOT SOLD SEPARAT | CONINJECTION PUMP ASSY AD TYPE(CF GN040-131E)OEM PART NO:ME723044 |
| 2. | VAME723045 | [1] | GOVERNOR ASSY RFD TYPE(CF GN040-132G) | |
| 3. | VAME704457 | [1] | FEED PUMP | KOBFUEL FEED PUMP ASSY KE TYPE(CF GN040-133B,DKC 1052104661)OEM PART NO:ME036703 |
| 4. | VAME047226 | [1] | AUTOMATIC TIMER ASSY SA TYPE(CF GN040-1340) | |
| 5A. | VAME717108 | [1] | SUPPORT | KOBSWITCH,MICRO(DKC 1531689320) Superseded by part number: VAME036799 |
| 6. | VAME066028 | [2] | CAP,SEAL(DKC 1540620400) | |
| 7. | VAME035679 | [1] | CLUTCH DISC | KOBCLUTCH DISK DISK,DRIVING(HD 0924360180) Superseded by part number: VAME076553 |
| 8. | VAMH035580 | [1] | O-RING 140 | |
| 9. | VAME036954 | [1] | STAY.I/P | |
| 10. | VAMF140223 | [4] | BOLT | KOBBOLT, FLANGE 8X16 |
| 14. | VAMF434105 | [4] | NUT | KOBNUT,FLANGE 10 |
| 15. | VAMF434105 | [4] | NUT | KOBNUT,FLANGE 10 |
| 24. | VAME036955 | [1] | SPACER | |
