HK50571
|
[1] |
BELT DRIVE SPEED UP KIT COMPLETE
|
|
| 1. |
433-820
|
[10] |
CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 1 1/4", Gr 5
|
CAS
1/2-13 X 1-1/4 RHSNB Superseded by part number: 87868
|
| 2. |
231-5348
|
[20] |
FLANGE NUT,Flg, 1/2"-13
|
CAS
1/2-13 HFTLN GR/G Superseded by part number: 86521610
|
| 3. |
51200338
|
[2] |
BOLT
|
CAS
EYEBOLT
|
| 4. |
700709676
|
[1] |
BELT,37.00 mm W
|
CAS
Cog 37.00 mm W
|
| 5. |
700709679
|
[1] |
SPROCKET ASSY.
|
CAS
SPROCKET - cog
|
| 6. |
700709682
|
[1] |
BUSHING
|
CAS
HUB - tapered
|
| 7. |
360-816
|
[2] |
BOLT,Hex, 1/2" - 13 x 1", Gr 8
|
CAS
1/2-13 X 1 HFS GR8 Superseded by part number: 87034823
|
| 8. |
121-237
|
[2] |
SERRATED BOLT,Hex, 3/8" - 16 x 1 1/4, Spcl
|
CAS
3/8-16 X 1-1/4 HFS GR8 Superseded by part number: 87327172
|
| 9. |
495-21044
|
[1] |
WASHER,3/8"
|
CAS
Superseded by part number: 87779090, 80702
|
| 10. |
232-5316
|
[8] |
FLANGE NUT,Flg, 3/8"-16
|
CAS
3/8-16 HFTLN GR/G Superseded by part number: 86521609
|
| 11. |
700120801
|
[1] |
SUPPORT
|
HFI
BRACE - chute
|
| 12. |
434-616
|
[6] |
CARRIAGE BOLT,Sht Sq Nk, 3/8" - 16 x 1", Gr 5
|
CAS
3/8-16 X 1 RHSNB Superseded by part number: 80280503
|
| 13. |
425-108
|
[4] |
NUT,1/2" - 13, Gr 5
|
CAS
NUT, , Hex 1/2"-13, G5 Superseded by part number: 280431
|
| 14. |
700117981
|
[2] |
PLATE
|
HFI
- bearing
|
| 15. |
714360
|
[4] |
FLANGED BEARING
|
IH
FLANGE - bearing
|
| 16. |
712158
|
[2] |
SPHERICAL BEARING,2" ID x 100 mm OD
|
L
BEARING - spherical Superseded by part number: 47577203
|
| 17. |
700117980
|
[4] |
STRAP
|
HFI
- shield
|
| 18. |
700117997
|
[1] |
SUPPORT
|
HFI
- front, bearing
|
| 19. |
6595805
|
[1] |
BUCKET TOOTH KEY
|
IH
1/2 X 1/2 X 4 KEY
|
| 20. |
86636814
|
[1] |
LUBE NIPPLE,1/4"-28 x .52" lg
|
GI
Superseded by part number: 88775
|
| 21. |
61879
|
[1] |
KEY
|
CAS
1/2 X 1/2 X 2-1/2 KEY
|
| 22. |
700709839
|
[1] |
BUSHING
|
CAS
HUB - tapered
|
| 23. |
700709681
|
[1] |
SPROCKET ASSY.
|
CAS
SPROCKET - cog
|
| 24. |
700117982
|
[1] |
SHAFT
|
HFI
JACKSHAFT
|
| 25. |
700120802
|
[1] |
SHIELD
|
HFI
- drive
|
| 26. |
340-1108
|
[4] |
SCREW,Cross Pan Hd, #10-24 x 1/2"
|
CAS
#10-24 X 1/2 CRPHMS
|
| 27. |
492-11010
|
[4] |
LOCK WASHER,#10
|
CAS
WASHER, LOCK, #10 Superseded by part number: 80684
|
| 28. |
225-14110
|
[4] |
NUT,#10-24
|
CAS
Superseded by part number: 87304
|
| 29. |
700711665
|
[1] |
DECAL
|
CAS
- notice
|
| 30. |
700120803
|
[2] |
STRAP
|
HFI
- shield
|
| 31. |
433-512
|
[4] |
CARRIAGE BOLT,Sq Nk, 5/16" - 18 x 3/4", Gr 5
|
CAS
Superseded by part number: 280327
|
| 32. |
232-5315
|
[4] |
FLANGE NUT,Flg, 5/16"-18
|
CAS
5/16-18 HFTLN GR/G
|
| 33. |
700706849
|
[2] |
LATCH
|
CAS
- fastener
|
| 34. |
433-828
|
[8] |
CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 1 3/4", Gr 5
|
CAS
1/2-13 X 1-3/4 RHSNB Superseded by part number: 88530
|
| 35. |
700711557
|
[8] |
WASHER
|
CAS
1/2 HARDENED WIDE PLAIN WASHER
|
