| 1. |
1700145
|
[1] |
COUPLING
|
IH
COUPLER - draper
|
| 2. |
360-816
|
[6] |
BOLT,Hex, 1/2" - 13 x 1", Gr 8
|
CAS
1/2-13 X 1 HFS GR8 Superseded by part number: 87034823
|
| 3. |
231-5348
|
[14] |
FLANGE NUT,Flg, 1/2"-13
|
CAS
1/2-13 HFTLN GR/G Superseded by part number: 86521610
|
| 4. |
700117527
|
[1] |
ANGLE
|
HFI
- rear
|
| 5. |
700707954
|
[1] |
MAT
|
IH
DRAPER
|
| 6. |
433-824
|
[8] |
CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 1 1/2", Gr 5
|
CAS
1/2-13 X 1-1/2 RHSNB Superseded by part number: 280420, 72187237
|
| 7. |
700117514
|
[1] |
PIPE
|
HFI
|
| 8. |
H747188
|
[2] |
FLANGED BEARING,112.73 mm OD x 8.74 mm
|
CAS
FLANGE - bearing
|
| 9. |
2419CHA
|
[1] |
SPHERICAL BEARING,31.75mm ID x 62mm OD x 18mm W
|
CAS
BEARING
|
| 10. |
434-616
|
[3] |
CARRIAGE BOLT,Sht Sq Nk, 3/8" - 16 x 1", Gr 5
|
CAS
3/8-16 X 1 RHSNB Superseded by part number: 80280503
|
| 11. |
232-5316
|
[3] |
FLANGE NUT,Flg, 3/8"-16
|
CAS
3/8-16 HFTLN GR/G Superseded by part number: 86521609
|
| 12. |
700117427
|
[1] |
ROLLER
|
HFI
- drive
|
| 13. |
111-237
|
[3] |
CARRIAGE BOLT,Short NK, 5/16"-18 x 1", G5
|
CAS
BOLT, CARRIAGE, Short NK, 5/16"-18 x 1", G5 Superseded by part number: 33-516
|
| 14. |
232-5315
|
[7] |
FLANGE NUT,Flg, 5/16"-18
|
CAS
5/16-18 HFTLN GR/G
|
| 15. |
51200380
|
[2] |
FLANGE
|
CAS
- bearing
|
| 16. |
50302
|
[3] |
SPHERICAL BEARING,25.4 mm ID x 52 mm OD x 30.96 mm
|
CAS
- special Superseded by part number: 204807C91, 47577183
|
| 17. |
700117998
|
[1] |
SUPPORT
|
HFI
|
| 18. |
700117501
|
[1] |
FRAME
|
HFI
CONVEYOR - primary
|
| 19. |
700117530
|
[1] |
SUPPORT
|
HFI
- intermediate
|
| 20. |
700117494
|
[2] |
SUPPORT
|
HFI
- tightener
|
| 21. |
700117434
|
[1] |
ROLLER
|
HFI
- idler
|
| 22. |
700117491
|
[1] |
SCRAPER
|
HFI
|
| 23. |
113-225
|
[2] |
BOLT,Hex, 3/8" - 16 x 5", Gr 5, Full Thd
|
CAS
Superseded by part number: 87657981
|
| 24. |
496-11041
|
[4] |
WASHER,13/32" x 13/16" x .065", HDN
|
CAS
3/8 HARDENED PLAIN WASHER Superseded by part number: 86632588
|
| 25. |
50591
|
[4] |
FLANGE,52mm
|
IH
- bearing Superseded by part number: 86548974
|
| 26. |
121-108
|
[4] |
BOLT,Hex Flg, 5/16"-18 x 1 1/4", Serr
|
CAS
5/16-18 X 1 HWHMS
|
