HK50517
|
[1] |
CONVEYOR EXTENSION KIT COMPLETE
|
|
| 1. |
700708070
|
[2] |
STRAP
|
CAS
WITH HOOKS
|
| 2. |
700708072
|
[1] |
APRON
|
CAS
- belting
|
| 3. |
231-5348
|
[18] |
FLANGE NUT,Flg, 1/2"-13
|
CAS
1/2-13 HFTLN GR/G Superseded by part number: 86521610
|
| 4. |
700117518
|
[2] |
SUPPORT
|
IH
- extension, rear
|
| 5. |
700117528
|
[2] |
U-BOLT,U, 1/2" - 13 x 8.465"
|
IH
1/2-13 U-BOLT
|
| 6. |
700117509
|
[1] |
PIVOT
|
IH
- rear
|
| 7. |
433-828
|
[4] |
CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 1 3/4", Gr 5
|
CAS
1/2-13 X 1-3/4 RHSNB Superseded by part number: 88530
|
| 8. |
433-824
|
[10] |
CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 1 1/2", Gr 5
|
CAS
1/2-13 X 1-1/2 RHSNB Superseded by part number: 280420, 72187237
|
| 9. |
360-816
|
[4] |
BOLT,Hex, 1/2" - 13 x 1", Gr 8
|
CAS
1/2-13 X 1 HFS GR8 Superseded by part number: 87034823
|
| 10. |
700117521
|
[1] |
SUPPORT
|
IH
- pivot, front
|
| 11. |
700117615
|
[1] |
PIVOT
|
IH
- front
|
| 12. |
219-8
|
[2] |
LUBE NIPPLE,1/4" - 28 NPTF
|
CAS
NIPPLE, LUBE, 1/4"-28 NPT x .54" lg Superseded by part number: 87414
|
| 13. |
700117525
|
[1] |
SUPPORT
|
HFI
- cylinder
|
| 14. |
700117988
|
[1] |
SUPPORT
|
IH
- extension, front
|
| 15. |
433-512
|
[10] |
CARRIAGE BOLT,Sq Nk, 5/16" - 18 x 3/4", Gr 5
|
CAS
Superseded by part number: 280327
|
| 16. |
232-5315
|
[18] |
FLANGE NUT,Flg, 5/16"-18
|
CAS
5/16-18 HFTLN GR/G
|
| 17. |
496-11041
|
[6] |
WASHER,13/32" x 13/16" x .065", HDN
|
CAS
3/8 HARDENED PLAIN WASHER Superseded by part number: 86632588
|
| 18. |
738468
|
[1] |
O-RING
|
IH
|
| 19. |
218-5105
|
[2] |
ELBOW,90 Degree Elbow, 9/16" - 18 Male JIC x 9/16" - 18 Male ORB
|
CAS
(Includes item 18) 90º, 9/16"-18, 37º x 9/16"-18, O-Ring Superseded by part number: 76344, 72186128
|
| 20. |
700704318
|
[1] |
CYLINDER
|
HFI
- hydraulic Superseded by part number: 700712023
|
| . . |
700712023
|
[1] |
CYLINDER
|
CAS
- hydraulic
|
| 21. |
1-7141
|
[2] |
FITTING
|
CAS
- male, quick disconnect Superseded by part number: 1272770C2
|
| 22. |
529070
|
[1] |
CABLE TIE,368.3mm L
|
NH
TIE - cable
|
| 23. |
700708437
|
[2] |
HOSE
|
CAS
- hydraulic
|
| 24. |
700117512
|
[1] |
CHUTE ASSY.
|
HFI
CHUTE - inner
|
| 25. |
434-58
|
[8] |
CARRIAGE BOLT,Sht Sq Nk, 5/16" - 18 x 1/2", Gr 5
|
CAS
BOLT CARRIAGE, Short NK, 5/16"-18 x 1/2", G5, Full Thd Superseded by part number: 280616
|
| 26. |
700117513
|
[1] |
CHUTE ASSY.
|
HFI
CHUTE - outer
|
