纽荷兰零件查询(F5HFL413B A002) - ENGINE 5801438206 - 84393712 (10.304.01[01]) - PUMP, ENGINE OIL & RELATED PARTS (5801406438) New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
802 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 504226579 | [1] | DIPSTICK | TORASSY Contains Ref.1A, 2, 3. |
| 2. | 504027969 | [1] | SEALING RING | TORSEALRING |
| 3. | 14452981 | [2] | O-RING,0.07" Thk x 0.364" ID, -12, Cl 7, 75 Duro | NH |
| 4. | 504382195 | [1] | PRESSURE RELIEF VALVE | TORASSY Contains Ref.4A, 12. |
| 4A. | NSS | [1] | NOT SERVICED SEPARATELY | CON |
| 5. | 504087621 | [1] | | NECK FILLER |
| 6. | 14458681 | [1] | O-RING,1.487" ID x 0.103" Width | LEC |
| 7. | 16677735 | [2] | SCREW,M12 x 25mm | TOR |
| 8. | 16673635 | [2] | BOLT,Hex, M8 x 1.25 x 20mm, Full Thd | TOR Superseded by part number: 16978124 |
| 9. | 16588225 | [1] | BOLT,Hex, M12 x 1.75 x 40mm | TOR |
| 10. | 2853410 | [1] | FILLER CAP | TORASSY Contains Ref.10A, 11. Superseded by part number: 500301568 |
| 11. | 2853412 | [1] | O-RING,0.21" Thk x 1.475" ID | TOR Superseded by part number: 17295480 |
| 12. | 5135738 | [1] | O-RING,0.103" Thk x 0.674" ID, -115, 80 Duro | TTF |
