神钢零件查询(6D15-T) - MITSUBISHI DIESEL ENGINE - K909 II & K909LC II EXCAVATORS (1/87-12/06) (02-010) - FUEL INJECTION PIPE Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
800 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | VAME070831 | [1] | INJECTION PIPE | KOBPIPE,INJECTION ,NO.1 |
| 2. | VAME070832 | [1] | INJECTION PIPE | KOBPIPE,INJECTION,NO.2 |
| 3. | VAME070833 | [1] | INJECTION PIPE | KOBPIPE,INJECTION,NO.3 |
| 4. | VAME070834 | [1] | INJECTION PIPE | KOBPIPE,INJECTION,NO.4 |
| 5. | VAME070835 | [1] | INJECTION PIPE | KOBPIPE,INJECTION,NO.5 |
| 6. | VAME070836 | [1] | INJECTION PIPE | KOBPIPE,INJECTION,NO.6 |
| 7. | VAMH020258 | [4] | CLAMP | KOBCLAMP Superseded by part number: 134717A1 |
| 8. | VAMH020259 | [2] | CLAMP | KOBCLAMP Superseded by part number: 134718A1 |
| 9. | VAMH020260 | [1] | CLAMP | KOBCLAMP |
| 10. | VAMH021252 | [1] | CLAMP | KOBCLAMP |
| 11. | VAMF240029 | [4] | SCREW | KOBB0LT,W/WSR 6X25 |
| 12. | VAMF434103 | [1] | NUT | KOBNUT.FLANGE 6 |
