纽荷兰零件查询(F5HFL413B A002) - ENGINE 5801438206 - 84393712 (10.400.01) - PIPING - ENGINE COOLING SYSTEM (504386309) New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
550 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 504182961 | [1] | PIPE | TOR- ASSY Contains Ref.2 |
| 2. | 17289081 | [1] | O-RING,31.34mm ID x 3.53mm | TORD. 31,34X3,53 mm |
| 3. | 10300714 | [1] | PLUG,M16 x 1.5 x 14 | TTFM16 x 1.5 |
| 4. | 4858609 | [1] | O-RING | TTFD = 16 x 20 |
| 5. | 2854311 | [1] | SCREW | TORM8X1,25X18 mm |
| 6. | 16993711 | [1] | PLUG,M35 x 1.5 | TOR |
| 7. | 99469380 | [1] | GASKET,33mm ID x 45mm OD x 2.8mm Thk | TOR |
| 8. | 16994611 | [1] | PLUG | TOR |
