神钢零件查询(6D15-T) - MITSUBISHI DIESEL ENGINE - K909 II & K909LC II EXCAVATORS (1/87-12/06) (02-012) - FUEL INJECTION NOZZLE Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
466 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 6D152CT-YJ01 | [1] | FUEL INJECTION NOZZLE(M9) | |
| . . | 6D160WT-KS12 | [1] | FUEL INJECTION NOZZLE(M7) | |
| 1-12. | VAME047437 | [6] | NOZZLE ASSY 180KG/CM2,FOR M7 ONLY | |
| 1-11. | VAME705437 | [6] | NOZZLE HOLDER ASSY | |
| 1-12. | VAME070762 | [6] | NOZZLE | KOB180KG/CM2,FOR M9 ONLY |
| 1. | VAME705400 | [6] | SCREW | KOBBOLT,EYE Superseded by part number: 77270082, 134650A1 |
| 2. | VAME705389 | [12] | PACKING | KOBGASKET Superseded by part number: 134686A1 |
| 4. | VAME705404 | [6] | SCREW ADJUS SCREW,ADJUSTING | SCREW ADJUS SCREW,ADJUSTING |
| 3. | VAME705403 | [6] | NUT | KOBNUT.CAP |
| 5. | VAME705409 | [6] | SPRING | KOBSPRING,NOZZLE Superseded by part number: 133275A1 |
| 6. | VAME705406 | [6] | PUSH ROD | KOBROD,PUSH Superseded by part number: 134708A1 |
| 7. | VAME705391 | [6] | GASKET | KOBGASKET Superseded by part number: 134652A1 |
| 8. | NSS | [6] | NOT SOLD SEPARAT | CONBODY,NOZZLE HOLDER,FOR F1 ONLY |
| 8A. | VAME705407 | [12] | PIN | KOBPIN Superseded by part number: 77270085, 134711A1 |
| 9. | VAME705426 | [6] | HYD CONNECTOR | KOBCONNECTOR,INLET |
| 10. | VAME705425 | [6] | GASKET | KOBGASKET Superseded by part number: VA1506022700 |
| 11. | VAME705402 | [6] | NUT | KOBNUT,RETAINING |
| 12. | VAME047129 | [6] | TIP | KOBTIP,NOZZLE 0.31-5,FOR M7 ONLY |
| 13. | VAME036562 | [6] | DUST CAP | KOBSEAL,DUST |
| 12. | VAME723943 | [6] | NOZZLE | KOBTIP,NOZZLE0,31-5 ,FOR M9 ONLY |
| 14. | VA3096102300 | [6] | O-RING | KOBGASKET,NOZZLE TIP |
| 15. | VAMH000656 | [12] | SET SCREW | KOBBOLT,NOZZLE HOLDER |
