纽荷兰零件查询(F5HFL413B A002) - ENGINE 5801438206 - 84393712 (10.414.03) - BELT PULLEY DRIVE & COVER (5801440012) New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
927 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 5801393171 | [1] | BRACKET, SUPPORTING | TORASSY |
| 2. | 4892732 | [1] | BALL BEARING,34mm ID x 64mm OD x 37mm W | TOR |
| 3. | 4890732 | [1] | RETAINER,11.50mm ID x 52mm OD x 7mm | TOR |
| 4. | 32324 | [1] | SNAP RING,2.44", Int, #244 | GI |
| 5. | 16592924 | [1] | SCREW,M10 x 1.5 x 80mm | TOR Superseded by part number: 16592925 |
| 6. | 4892426 | [1] | HUB | TOR |
| 7. | 16673735 | [5] | BOLT,Hex, M8 x 1.25 x 25mm | TOR Superseded by part number: 10278301 |
| 8. | NSS | [1] | NOT SERVICED SEPARATELY | CON |
| 9. | 18139424 | [4] | SCREW,Hex, M10 x 20mm | TOR |
| 10. | 5801420820 | [1] | PULLEY | TOR |
