纽荷兰零件查询(F5HFL463A F001) - ENGINE 5801390425 - 84315306 (47374655) (10/13-) (10.102.AK) - CRANKCASE, COVER New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
806 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 5801526739 | [1] | COVER | TORASSY, Incl 3, 4, 7, 8, 10, 11 |
| 2. | 504379050 | [1] | GASKET | TOR |
| 3. | 504051236 | [1] | PLUG,Threaded, 1/8" | TOR |
| 4. | 99469381 | [1] | GASKET | TOR |
| 5. | 16586725 | [1] | BOLT,Hex, M8 x 1.25 x 40mm | TOR |
| 6. | 16730924 | [3] | | STUD |
| 7. | 16727724 | [3] | | STUD |
| 8. | 16586625 | [15] | BOLT,M8 x 35mm | TOR |
| 9. | 4798844 | [3] | SCREW | FOR |
| 10. | 16586925 | [7] | BOLT,M8 x 50mm | TOR |
| 11. | 5801598442 | [1] | COVER | TORASSY, Incl 12-14 |
| 13. | NSS | [1] | NOT SERVICED SEPARATELY | CONCover, Incl in 11 |
| 14. | 16882515 | [1] | PLUG | TOR |
