纽荷兰零件查询(F5HFL463A F001) - ENGINE 5801390425 - 84315306 (47374655) (10/13-) (10.102.AP) - ENGINE OIL PAN New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
794 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 504179445 | [1] | ENGINE OIL PAN | TORASSY, Incl 2, 3, 8 |
| 2. | NSS | [1] | NOT SERVICED SEPARATELY | CONIncl in 1 |
| 3. | 5135740 | [1] | O-RING,0.924" ID x 1.13" OD x 0.103" | TTF Superseded by part number: 14457780 |
| 4. | 5801363457 | [1] | SPACER | TOR |
| 5. | 504179443 | [1] | OIL PAN GASKET SET | TOR |
| 6. | 16586625 | [11] | BOLT,M8 x 35mm | TOR |
| 7. | 504049517 | [2] | SCREW | TOR |
| 8. | 4894139 | [1] | PLUG,Hex Soc, M22 x 1.5 | TOR |
| 9. | 504179050 | [1] | FILTER STRAINER | TOR |
| 10. | 18139424 | [2] | SCREW,Hex, M10 x 20mm | TOR |
| 11. | 16689024 | [1] | SCREW,M16 x 12mm | TOR |
| 12. | 2852978 | [1] | O-RING,0.103" Thk x 0.924" ID, -119, Cl 7, 75 Duro | TOR Superseded by part number: 14457780 |
